ABB Analog input option board. 2 AI: Thermocouple B, E, J, K, N, R, S, T. 16 Bit. Spring terminals included (TA5123-2AI-RTD)

ABB Analog input option board. 2 AI: Thermocouple B, E, J, K, N, R, S, T. 16 Bit. Spring terminals included (TA5123-2AI-RTD)

SKU: TA5122-2AI-TCAlt SKU: TA5122-2AI-TCMPN: 1SAP187100R0004
Price on application Contact us for pricing and availability.
Call 01708 343600

Why Choose the ABB TA5122-2AI-TC AC500-eCo Thermocouple Input Option Board [TA5122-2AI-TC]?

The ABB TA5122-2AI-TC (order code 1SAP187100R0004) is an analog input option board for the AC500-eCo PLC range, adding two thermocouple inputs for temperature measurement.

The board supports thermocouple types B, E, J, K, N, R, S and T with 16-bit resolution, and connects via a 6-pole spring front terminal with 3.50 mm pitch. It plugs directly onto an AC500-eCo CPU to expand its on-board analog measurement capability.

Key Features

  • 2 analog thermocouple inputs
  • Thermocouple types B, E, J, K, N, R, S, T
  • 16-bit resolution
  • AC500-eCo option board format
  • 6-pole spring front terminal, 3.50 mm pitch
  • Compact, plug-on expansion

Applications

  • Temperature measurement
  • AC500-eCo I/O expansion
  • Process and machine monitoring
  • Thermocouple-based control

Trusted By Customers Worldwide

"A dependable choice we specify for reliable industrial control and automation builds." Controls Engineer, UK

Technical Specifications

Tick the specs you need, then view products that match.

Device Type Analogue I/O Module
Analogue I/O 2 AI / 0 AO
Signal Type / Function Analogue, Temperature (RTD/TC)
Number of I/O 4
Signal / Input Range Thermocouple
Product Series ABB AC500-eCo
Manufacturer ABB
Series AC500-eCo
Order Code 1SAP187100R0004
Model TA5122-2AI-TC
Channels 2 AI (thermocouple)
Thermocouple Types B, E, J, K, N, R, S, T
Resolution 16-bit
Terminal 6-pole spring, 3.50 mm pitch

Frequently Asked Questions

How many inputs does the board provide?
It provides 2 analog thermocouple inputs.
Which thermocouple types are supported?
Types B, E, J, K, N, R, S and T, at 16-bit resolution.
Where does it fit?
It is an option board that plugs onto an AC500-eCo CPU to add thermocouple measurement.
What is the product code for this item?
The product SKU / order code is TA5122-2AI-TC.
Where can I find standards and approvals?
Please refer to the manufacturer's data sheet for full standards, approvals and detailed specifications.
