Why Choose the ABB CI504-PNIO-XC PROFINET Communication Interface Module?
The ABB CI504-PNIO-XC, part number 1SAP421300R0001, is a PROFINET IO RT device and gateway module designed for ABB AC500-XC automation systems. It provides a reliable communication interface between a PROFINET network and serial field devices through three configurable RS232, RS422 or RS485 interfaces.
The CI504-PNIO-XC combines two Ethernet ports with integrated switch functionality and three serial interfaces supporting ASCII communication. This configuration enables serial devices to be integrated into PROFINET-based automation architectures while supporting straightforward network daisy chaining and flexible industrial communication layouts.
As an XC version, the CI504-PNIO-XC is designed for applications requiring ABB equipment suitable for extreme environmental conditions. The communication interface module is installed on a compatible PROFINET IO terminal unit, such as the TU520-ETH-XC, allowing the module to be integrated into AC500-XC systems while simplifying wiring and module replacement.
Key Advantages
- PROFINET IO RT device for integration into industrial Ethernet automation networks.
- Three serial interfaces supporting RS232, RS422 and RS485.
- ASCII protocol support for communication with compatible serial devices.
- Two Ethernet ports with integrated switch functionality for flexible network connections.
- Supports simple PROFINET network daisy chaining.
- XC design for demanding industrial and extreme-environment applications.
- Compatible with ABB AC500-XC automation architectures and suitable PROFINET terminal units.
Key Features
- ABB AC500-XC PROFINET communication interface module.
- PROFINET IO RT device functionality.
- 3 serial interfaces.
- Selectable RS232, RS422 or RS485 physical layers.
- ASCII serial communication protocol.
- Configurable serial transmission rate from 300 bit/s to 115.2 kbit/s.
- 2 Ethernet interfaces with integrated switch functionality.
- Ethernet ports suitable for simple daisy-chain network topologies.
- Rotary switches for setting the PROFINET device identifier.
- Status LEDs for module and serial interface diagnostics.
- I/O bus interface for system extension.
- Designed for installation with a compatible PROFINET IO terminal unit.
- XC version for extreme environmental conditions.
Reliable PROFINET Communication for Industrial Automation
The ABB CI504-PNIO-XC provides a practical gateway between PROFINET IO and serial field devices. Its three serial interfaces can be configured for RS232, RS422 or RS485 communication, allowing compatible serial equipment to be positioned close to the required process or machine location while communicating through the PROFINET network.
With two Ethernet ports and integrated switch functionality, the CI504-PNIO-XC supports flexible network layouts and straightforward daisy chaining. Combined with the AC500-XC platform and compatible PROFINET terminal unit, it provides a compact communication solution for demanding industrial automation installations.
Typical Applications
- PROFINET-based industrial automation systems.
- Integration of serial field devices into PROFINET networks.
- RS232, RS422 and RS485 device communication.
- Machine and production-line automation.
- Distributed industrial communication architectures.
- AC500-XC PLC systems.
- Remote positioning of serial devices using PROFINET networking.
- Industrial installations requiring XC-rated automation equipment.
