Why Choose the WAGO 750-404/040-003 Counter Module?
The WAGO 750-404/040-003 is a robust counter module designed for high-performance signal measurement within the WAGO I/O System 750 XTR Series. It enables precise monitoring of digital pulse signals from devices such as encoders, sensors and speed measurement equipment in industrial automation environments.
This module is capable of counting pulses with switching frequencies up to 100 kHz and supports 32-bit counter depth, allowing accurate measurement of high-speed signals. It processes 24 V DC digital inputs and transmits measurement data directly to the fieldbus controller for use in machine monitoring, motion control and process automation applications. :contentReference
Built for demanding environments, the module belongs to the 750 XTR extreme-temperature series, offering reliable operation across extended temperature ranges and in harsh industrial conditions. Its compact DIN rail design and WAGO CAGE CLAMP® connection technology allow quick installation and dependable wiring in control cabinets.
Key Advantages
- High-precision digital pulse counting up to 100 kHz.
- 32-bit counter depth for accurate signal measurement.
- Designed for the WAGO 750 XTR modular I/O system.
- Handles 24 V DC digital signals from encoders and sensors.
- Suitable for harsh industrial environments with extended temperature operation.
- Compact DIN rail module for high-density automation cabinets.
Key Features
- Counter module for pulse and frequency measurement.
- 24 V DC signal inputs.
- Maximum switching frequency up to 100 kHz.
- 32-bit counter resolution.
- Supports up/down counting and frequency measurement modes.
- LED indicators for channel and module status.
- CAGE CLAMP® spring terminals for secure wiring.
- Compatible with WAGO 750 XTR fieldbus couplers and controllers.
Industrial Pulse Counting and Frequency Measurement
Counter modules are essential components in automation systems where equipment must monitor pulses, speed or frequency signals generated by sensors and encoders. By counting digital pulses from field devices, controllers can determine machine speed, detect rotational movement or measure process frequencies in real time.
High-speed counter modules such as the WAGO 750-404/040-003 are commonly used in manufacturing systems, packaging equipment and process control installations where accurate signal measurement is required.
Typical Applications
- Encoder pulse counting in motion control systems.
- Machine speed and rotation monitoring.
- Frequency measurement of sensor signals.
- Industrial automation and production machinery.
- Packaging, conveyor and material handling systems.
