WAGO 750-461/025-000 analogue input module with two channels for Pt100 RTD temperature sensors used in WAGO 750 Series distributed I/O systems.
£342.31
The WAGO 750-461/025-000 is a reliable 2-channel analogue input module designed for the WAGO 750 Series distributed I/O system. It enables direct connection of Pt resistance temperature sensors, converting temperature measurements into digital values for PLCs and industrial automation controllers.
This module supports Pt100 and other RTD sensors using two-wire or three-wire connections and automatically linearises the full temperature range to ensure accurate readings. Integrated diagnostics detect sensor faults such as line breaks, short circuits or measurement range errors, providing clear status indication via front-panel LEDs. :contentReference
With seamless integration into WAGO fieldbus couplers and controllers, the 750-461/025-000 provides dependable temperature monitoring across industrial processes, machinery and building automation systems.
Resistance temperature detectors such as Pt100 sensors are widely used in industrial automation because they provide stable and accurate temperature measurement across a wide range of applications. RTD sensors are commonly used in process control systems, HVAC installations and machine monitoring.
The WAGO 750-461/025-000 integrates these sensor signals into PLC and automation systems, enabling reliable monitoring, data acquisition and process control across distributed industrial networks. :contentReference
| IP Rating | IP20 |
|---|---|
| Series | WAGO 750 Series I/O System |
| Module type | RTD analogue input module |
| Number of inputs | 2 |
| Sensor type | Pt resistance temperature sensors (e.g. Pt100) |
| Connection types | 2-wire or 3-wire RTD |
| Resolution | 16-bit measurement data |
| Diagnostic functions | Line break, short circuit and range monitoring |
| System supply | 5 V DC via data contacts |
| Connection technology | WAGO CAGE CLAMP® terminals |
| Mounting | DIN rail (EN 60715) |
| Protection rating | IP20 |
| Operating temperature | Industrial operating range |
| Module width | approx. 12 mm |
| HS Code | 85389099 |
| Country of Manufacture | Germany |
The module measures temperature signals from RTD sensors such as Pt100 and converts them into digital values for PLC and automation systems.
The module provides two independent analogue input channels, allowing two RTD temperature sensors to be monitored.
The module supports Pt resistance temperature detectors, including Pt100 sensors.
The module supports both 2-wire and 3-wire RTD sensor connections, providing flexibility for different installation requirements.
The module is designed for the WAGO 750 Series distributed I/O system and operates with WAGO fieldbus couplers and programmable controllers.
WAGO 750 Series I/O modules are widely trusted by automation engineers and system integrators to build reliable distributed control systems across industrial automation environments.
