WAGO 750-469/040-000 analogue voltage input module with two channels for 0-10 V signals designed for WAGO 750 Series XTR distributed I/O systems.
£469.35
The WAGO 750-469/040-000 is a robust 2-channel analogue voltage input module designed for use within the WAGO 750 Series XTR distributed I/O system. It enables PLCs and automation controllers to measure voltage signals from industrial sensors and convert them into digital values for monitoring, control and process automation.
The module processes 0–10 V DC analogue signals, a widely used standard across industrial automation and building control systems. Its XTR design provides enhanced resistance to vibration, electromagnetic interference and extreme temperatures, making it suitable for harsh industrial environments.
When integrated with WAGO fieldbus couplers and controllers, the 750-469/040-000 provides reliable signal acquisition for distributed automation systems used in manufacturing plants, energy infrastructure and demanding industrial installations.
Voltage-based analogue signals such as 0–10 V are widely used across automation systems to transmit measurement data and control signals. These signals are common in industrial sensors, actuators, speed controllers and HVAC systems.
Modules like the WAGO 750-469/040-000 convert these analogue signals into digital values for PLCs and automation controllers, enabling precise monitoring and control across distributed industrial automation networks.
| IP Rating | IP20 |
|---|---|
| Series | WAGO 750 Series XTR I/O System |
| Module type | Analogue voltage input module |
| Number of inputs | 2 |
| Signal type | Voltage input |
| Input range | 0–10 V DC |
| Signal characteristic | Single-ended |
| Resolution | 12-bit |
| Typical conversion time | ≤ 4 ms |
| Internal resistance | approx. 133 kΩ |
| System supply | 5 V DC via data contacts |
| Connection technology | WAGO CAGE CLAMP® |
| Mounting | DIN rail (EN 60715) |
| Operating temperature | approx. −40 °C to +70 °C |
| Protection rating | IP20 |
| Module width | approx. 12 mm |
The module measures analogue voltage signals from sensors and converts them into digital values for PLC and automation control systems.
The module provides two independent analogue voltage input channels.
The module supports standard 0–10 V DC analogue signals.
Yes. The XTR version is designed for demanding industrial environments with extended temperature range and increased EMC resistance.
The module is designed for the WAGO 750 Series XTR distributed I/O system and operates with compatible WAGO fieldbus couplers and controllers.
WAGO 750 Series I/O modules are trusted worldwide by automation engineers and system integrators to build reliable distributed control systems across demanding industrial automation environments.
