Why Choose the WAGO 750-626/020-002 Potential Distribution Module?
The WAGO 750-626/020-002 is a specialised potential distribution module with diagnostic functionality designed for the WAGO I/O System 750 and 753. It distributes the 24 V DC field supply across modular I/O systems while simultaneously monitoring the electrical insulation of the field supply network.
In addition to reliable power distribution, the module provides ground fault detection for the connected field supply. This diagnostic capability enables early detection of insulation faults, improving system reliability and supporting safety requirements in demanding industrial applications.
The module distributes power using internal power jumper contacts and provides additional field wiring terminals via CAGE CLAMP spring terminals. Its compact DIN rail design ensures seamless integration within modular automation nodes.
Key Advantages
- Distributes 24 V DC field supply across modular I/O systems.
- Provides ground fault monitoring for insulation detection.
- Improves system reliability and maintenance diagnostics.
- Supports high current distribution via power jumper contacts.
- Reduces wiring complexity in automation control cabinets.
- Compatible with WAGO I/O System 750 and 753.
Key Features
- Potential distribution module with ground fault diagnostics.
- Nominal field voltage: 24 V DC.
- Integrated insulation monitoring for field supply circuits.
- Power jumper contacts for internal supply distribution.
- LED indicators for supply and fault status.
- CAGE CLAMP spring terminals for reliable wiring.
- DIN-35 rail mounting for industrial control cabinets.
Power Distribution with Integrated Diagnostics
Reliable power distribution is essential in modern industrial automation systems where sensors, actuators and field devices depend on stable supply voltage. Faults such as insulation leakage or ground faults can disrupt system operation or damage connected equipment.
The WAGO 750-626/020-002 distributes the 24 V field supply while continuously monitoring the insulation resistance of the field network. This diagnostic capability allows engineers to detect developing faults early and maintain high system availability in industrial automation environments.
Typical Applications
- Distributed PLC and fieldbus I/O systems.
- Industrial machine control panels.
- Automation systems requiring insulation monitoring.
- Process automation and manufacturing equipment.
- Control cabinets using WAGO I/O System 750 or 753 nodes.
