Why Choose the Partex PA1-250CC Colour-Coded Slide-On Chevron Cable Markers?
The Partex PA1-250CC is a professional colour-coded slide-on chevron cable marker handy pack designed for clear and organised identification of electrical cables and conductors. Part of the Partex PA1 cable marking range, these size C markers are specified for cables with an outside diameter of 2.5–5.0 mm, providing a practical identification solution for electrical installations, control panels, machinery wiring and industrial maintenance.
The PA1 slide-on design allows individual markers to be positioned onto suitable cables or conductors, while the chevron-style profile supports the assembly of identification sequences. The colour-coded marking system provides visual differentiation between characters, helping installers recognise and organise cable identification references during assembly, testing and maintenance.
Supplied in a convenient handy pack containing 10 × 25 markers, giving a total of 250 markers, the Partex PA1-250CC is particularly useful for electricians, control panel builders, automation engineers and maintenance technicians who require an accessible assortment of colour-coded cable identification markers.
Whether used for identifying control wiring, organising electrical conductors or maintaining consistent cable references, the Partex PA1-250CC offers a compact, practical and professional approach to electrical cable marking.
Key Advantages
- Colour-coded identification: Provides visual differentiation between marker characters to support cable recognition.
- Slide-on installation: Allows markers to be fitted onto compatible cables and conductors during wiring assembly.
- Chevron marker design: Supports the arrangement of individual identification characters into cable reference sequences.
- Size C compatibility: Specified for cables with an outside diameter of 2.5–5.0 mm.
- Convenient handy pack: Keeps identification markers available for installation, workshop and maintenance tasks.
- 250 markers supplied: Contains 10 groups of 25 markers for practical cable identification work.
- Organised wiring: Helps technicians distinguish cables and conductors in complex electrical installations.
- Flexible identification: Individual markers can be combined to create suitable cable references.
- Professional panel wiring: Supports consistent identification in electrical control cabinets and automation equipment.
- Maintenance efficiency: Clear cable references help technicians trace conductors during inspection and fault-finding.
- Mechanical marking method: Does not require on-site printing equipment for the supplied pre-marked characters.
- Partex identification system: Part of a specialist cable and wire marking range used in professional electrical applications.
Key Features
- Partex PA1-250CC colour-coded cable marker handy pack.
- Part of the Partex PA1 slide-on marker series.
- Marker design: Chevron.
- Installation method: Slide-on.
- Marker size: C.
- Compatible cable outside diameter: 2.5–5.0 mm.
- Identification format: Colour coded.
- Individual markers suitable for arranging into identification sequences.
- Designed for professional cable and conductor identification.
- Handy pack presentation for convenient storage and selection.
- Pack configuration: 10 × 25 markers.
- Total pack quantity: 250 markers.
- Suitable for electrical installation, panel building and maintenance applications.
Reliable Colour-Coded Cable Identification for Electrical Installations
Clear cable identification is an important part of professional electrical installation and maintenance. The Partex PA1-250CC slide-on chevron cable markers provide a convenient method of identifying conductors using individual colour-coded markers that can be arranged into the required reference sequence.
The size C configuration is intended for cables with an outside diameter between 2.5 mm and 5.0 mm. Selecting the correct marker size is essential for achieving an appropriate fit. Cable diameter should be measured across the insulation rather than determined solely from the conductor's nominal cross-sectional area, as cables with the same conductor size can have different overall diameters.
The slide-on installation method is particularly useful during new wiring assembly, when the cable end is accessible. Markers can be threaded onto the conductor in the required order before final termination, helping installers create identification sequences that correspond to wiring diagrams, terminal schedules and equipment documentation.
The chevron-style marker design supports the grouping of individual characters into readable cable references. The colour-coded format adds a visual identification aid, which can be helpful when working with multiple conductors in control cabinets, machinery wiring systems and industrial automation equipment.
Correct installation requires the marker to be suitable for the cable's outside diameter and insulation characteristics. The marker should be positioned so that the identification remains visible and does not interfere with cable termination, conductor routing or adjacent electrical components. Excessive force should not be used when fitting markers onto cables outside the specified diameter range.
The handy pack format provides a practical selection of markers for workshop and site use. With 10 × 25 markers, the PA1-250CC offers a total of 250 identification markers, supporting repeated cable marking tasks without the need for on-site printing equipment.
For reliable identification, the completed marking sequence should be checked against the relevant wiring schedule before the conductor is terminated. Colour coding should be treated as an additional identification aid rather than a replacement for accurate cable references and documented electrical identification procedures.
Typical Applications
- Electrical control panel conductor identification.
- Industrial automation wiring.
- PLC input and output cable marking.
- Machinery control circuit identification.
- Electrical cabinet and enclosure wiring.
- Motor control panel conductor marking.
- Building services electrical installations.
- Electrical equipment manufacturing.
- OEM machinery wiring and assembly.
- Industrial maintenance and fault-finding.
- Electrical workshop cable preparation.
- Instrumentation and control wiring identification.
- Replacement and refurbishment of existing cable identification.
- Organised conductor identification during installation and commissioning.
