Why Choose the Partex RF66/FI/FLAG Red Insulated Flag Terminal?
The Partex RF66/FI/FLAG is a red insulated 90-degree flag terminal designed for convenient electrical connections where space is limited or a right-angle cable entry is preferred. Featuring a 6.3 mm × 0.8 mm female push-on receptacle, this terminal provides a practical connection solution for compatible male blade terminals in electrical control panels, machinery and wiring assemblies.
As part of the Partex insulated crimp terminal range, the RF66/FI/FLAG combines a crimp-style conductor connection with a right-angle push-on terminal configuration. Its flag design allows the conductor to approach the mating blade from the side, helping installers route cables neatly in compact electrical assemblies and equipment.
Supplied in a pack of 100 terminals, the Partex RF66/FI/FLAG is suitable for electrical contractors, panel builders, equipment manufacturers and industrial maintenance engineers. The red insulation supports easy identification during installation, while the 6.3 mm × 0.8 mm receptacle is designed for compatible standard flat blade connections.
Key Advantages
- 90-degree flag terminal design supports right-angle electrical connections.
- 6.3 mm × 0.8 mm female push-on receptacle for compatible male blade terminals.
- Red insulated construction assists with terminal identification and connection protection.
- Right-angle cable entry helps simplify wiring in confined electrical enclosures.
- Crimp termination supports secure mechanical attachment to correctly sized conductors.
- Push-on connection enables convenient assembly and disconnection during maintenance.
- Suitable for industrial control panels, equipment wiring and electrical component connections.
- Supplied in a practical pack of 100 for professional installation and workshop use.
Key Features
- Partex RF66/FI/FLAG insulated flag terminal.
- Female push-on receptacle with right-angle flag configuration.
- 6.3 mm nominal mating blade width.
- 0.8 mm nominal mating blade thickness.
- Red insulation colour.
- Crimp-style conductor termination.
- Designed for compatible flat male blade connectors.
- Compact connection arrangement for space-restricted electrical wiring.
- Suitable for professional electrical installation and maintenance applications.
- Pack quantity: 100 pieces.
Technical Specifications
- Manufacturer: Partex
- Product range: Insulated Flag Terminals
- Model: RF66/FI/FLAG
- Product type: Insulated female flag terminal
- Terminal configuration: Right-angle / flag
- Connection type: Female push-on receptacle
- Nominal mating blade width: 6.3 mm
- Nominal mating blade thickness: 0.8 mm
- Terminal size: 6.3 × 0.8 mm
- Insulation colour: Red
- Conductor termination: Crimp
- Mating connection: Compatible 6.3 × 0.8 mm male blade terminal
- Installation arrangement: 90-degree cable entry
- Pack quantity: 100
- Application: Electrical wiring and right-angle component connections
Reliable Right-Angle Connections for Compact Electrical Wiring
Flag terminals are designed to provide an alternative to conventional straight push-on connectors where wiring direction or available installation space makes a right-angle connection preferable. The Partex RF66/FI/FLAG uses a female receptacle configured to connect with a compatible 6.3 mm × 0.8 mm male blade, allowing the conductor to be routed approximately perpendicular to the blade connection.
Correct installation requires an appropriately sized conductor, suitable crimping equipment and a matching male blade terminal. The conductor should be stripped and crimped according to the terminal manufacturer's instructions, and the completed connection should be checked for secure engagement. The insulated flag configuration is particularly useful in control equipment, wiring harnesses and electrical assemblies where conventional straight terminals may be less convenient.
Typical Applications
- Industrial electrical control panel wiring.
- Space-restricted electrical enclosures and terminal connections.
- Electrical switchgear and control component wiring.
- Machinery and industrial automation equipment.
- Electrical appliances and equipment assemblies.
- OEM wiring harness manufacturing.
- Electrical maintenance and replacement terminal installations.
- Right-angle connections to compatible 6.3 × 0.8 mm male blade contacts.
