Why Choose the Partex YR84/RA M8 Yellow Ring Terminal?
The Partex YR84/RA is a professional yellow insulated ring terminal designed to provide secure and reliable electrical connections between stranded copper conductors and compatible screw or stud terminals. Featuring an M8 stud connection, this crimp terminal is suitable for industrial control panels, electrical distribution equipment, machinery wiring and other applications requiring dependable cable termination.
The yellow insulated crimp sleeve provides clear visual identification and insulation around the conductor termination area, while the closed-ring contact helps maintain secure mechanical retention when fitted to a compatible M8 fixing. The terminal's crimp barrel is designed to attach to an appropriately sized stranded copper conductor using a suitable insulated terminal crimping tool.
With its M8 ring connection and practical insulated design, the Partex YR84/RA is a useful choice for electrical installations requiring secure stud-mounted cable connections. Supplied in a convenient pack of 100, these terminals are ideal for electricians, control panel manufacturers, electrical contractors and industrial maintenance engineers.
Key Advantages
- Professional yellow insulated ring terminal for dependable electrical cable termination.
- M8 stud connection suitable for compatible threaded screws and studs.
- Yellow insulated sleeve provides easy visual identification and insulation around the crimp area.
- Closed-ring design helps prevent accidental disconnection when the fixing is correctly secured.
- Crimp termination provides secure mechanical attachment to appropriately sized stranded copper conductors.
- Suitable for industrial control panels, electrical distribution equipment and machinery wiring.
- Useful for new electrical assemblies, maintenance work and equipment refurbishment.
- Supplied in a practical pack of 100 ring terminals.
Key Features
- Partex YR84/RA insulated ring terminal.
- M8 ring connection for compatible stud or screw mounting.
- Yellow insulated crimp sleeve.
- Closed-ring metal contact for secure electrical connections.
- Crimp barrel designed for compatible stranded copper conductors.
- Suitable for installation using an appropriately sized insulated terminal crimping tool.
- Designed for compatible M8 electrical terminal connections.
- Suitable for electrical control panel assembly, industrial wiring and maintenance.
- 100 terminals per pack.
Technical Specifications
- Manufacturer: Partex
- Manufacturer part number: YR84/RA
- Product type: Insulated ring terminal / ring cable lug
- Terminal configuration: Closed ring
- Stud size: M8
- Insulation colour: Yellow
- Insulation type: Insulated crimp sleeve
- Termination method: Crimp
- Connection type: Screw / stud terminal
- Compatible conductor type: Appropriately sized stranded copper conductor
- Typical application: Electrical cable termination
- Pack quantity: 100 pieces
Secure M8 Ring Connections for Industrial Electrical Installations
Insulated ring terminals provide a dependable method of connecting stranded copper conductors to threaded electrical terminal studs. The Partex YR84/RA features a closed-ring contact designed for M8 fixings, helping ensure the terminal remains captured around the screw or stud until the fixing is removed. This makes ring terminals particularly useful in industrial electrical installations where secure mechanical retention and consistent electrical contact are important.
For correct installation, select a stranded copper conductor within the terminal's specified crimp capacity, strip the insulation to the appropriate length and insert the conductor fully into the crimp barrel. Use a suitable insulated terminal crimping tool and die to form a secure connection. Inspect the finished crimp before placing the ring over the compatible M8 stud and tightening the fixing according to the equipment manufacturer's torque recommendations. The yellow sleeve insulates the crimp area, but the metal ring remains exposed and must be suitably protected within the electrical installation.
Typical Applications
- Industrial electrical control panel wiring and assembly.
- Electrical distribution boards and switchgear equipment.
- Motor control centres and industrial machinery connections.
- PLC cabinets and industrial automation systems.
- M8 screw and stud-mounted electrical terminals.
- OEM electrical equipment manufacturing and assembly.
- Building management and HVAC control equipment.
- Electrical maintenance, repair and refurbishment.
