Why Choose the Partex SBSW20 White Spacer Bar Saddles?
The Partex SBSW20 is a white polyester powder-coated galvanised steel spacer bar saddle designed for securing 20 mm round electrical conduit to suitable mounting surfaces. Supplied in a convenient pack of 10, these conduit fixing accessories provide a practical solution for supporting surface-mounted conduit installations in commercial, industrial and building services environments.
Manufactured from galvanised steel with a white polyester powder-coated finish, the SBSW20 combines a robust metal construction with a neat, coordinated appearance. The galvanised steel base offers corrosion resistance, while the powder-coated surface provides an additional protective finish and helps the saddle blend into white conduit systems and surrounding installations.
The spacer bar saddle design holds compatible round conduit away from the mounting surface, providing clearance between the conduit and the wall, ceiling or supporting structure. This arrangement can be useful where surface conditions, installation requirements or conduit routing call for a raised fixing position.
Ideal for electrical contractors, maintenance engineers and building services installers, the Partex SBSW20 provides a straightforward method of securing 20 mm round conduit while maintaining a consistent white finish throughout the installation.
Key Advantages
- Designed for 20 mm round conduit to provide a compatible fixing solution for surface-mounted conduit systems.
- Galvanised steel construction offers strength and corrosion resistance for suitable installation environments.
- White polyester powder-coated finish provides an attractive, coordinated appearance and an additional protective surface layer.
- Spacer bar configuration maintains clearance between the conduit and its mounting surface.
- Suitable for professional conduit installations in electrical, commercial and industrial applications.
- Pack of 10 saddles provides a practical quantity for installation, maintenance and replacement work.
Key Features
- Partex SBSW20 spacer bar saddle.
- Designed for 20 mm diameter round conduit.
- Manufactured from galvanised steel.
- Finished with white polyester powder coating.
- Raised conduit support using a spacer bar saddle configuration.
- Suitable for fixing conduit to appropriate wall, ceiling and structural surfaces.
- Provides a neat fixing arrangement for compatible white conduit installations.
- Supplied in packs of 10 pieces.
Technical Specifications
- Manufacturer: Partex
- Product reference: SBSW20
- Model: SBSW20
- Product type: Spacer bar conduit saddle
- Compatible conduit type: Round conduit
- Nominal conduit size: 20 mm
- Base material: Galvanised steel
- Surface finish: Polyester powder coating
- Colour: White
- Mounting configuration: Surface-mounted spacer bar saddle
- Primary function: Supporting and securing round electrical conduit
- Pack quantity: 10 pieces
- Typical applications: Electrical conduit installation and cable containment support
- Fixing requirements: Select suitable fixings for the mounting surface and installation conditions
Reliable Support for 20 mm Round Conduit Installations
Surface-mounted conduit systems require suitable mechanical supports to maintain alignment, secure the conduit and protect the cables routed within it. The Partex SBSW20 white spacer bar saddle is designed for 20 mm round conduit, providing a raised fixing arrangement that helps keep conduit securely positioned along walls, ceilings and other suitable mounting surfaces.
Unlike a standard close-fitting conduit saddle, a spacer bar saddle creates clearance between the conduit and the mounting surface. This can be beneficial where the conduit needs to be held away from the substrate, where minor surface irregularities are present or where a consistent stand-off arrangement is preferred. The spacing can also make certain areas around the conduit more accessible during installation and maintenance.
The SBSW20 features a galvanised steel construction with a white polyester powder-coated finish. Galvanising helps protect the underlying steel against corrosion, while the powder coating adds a durable decorative finish. This combination makes the saddle particularly useful where a clean white appearance is important alongside dependable mechanical support.
For installation, the saddle should be positioned at an appropriate fixing point and secured using fasteners suitable for the mounting substrate. The conduit is then located within the saddle arrangement and fixed in accordance with the applicable installation method. Installers should follow relevant electrical installation requirements and determine suitable support spacing based on conduit material, size, loading and site conditions.
Where the installation is exposed to moisture, aggressive chemicals, coastal conditions or other demanding environments, the suitability of the galvanised and powder-coated finish should be confirmed for the specific application. Any damaged coating should be assessed to maintain the intended corrosion protection.
Typical Applications
- Surface-mounted 20 mm round electrical conduit installations.
- Commercial building electrical wiring and cable containment systems.
- Industrial machinery rooms, workshops and service areas.
- Electrical conduit routing along suitable walls and ceilings.
- White-finished conduit installations where a coordinated appearance is preferred.
- Maintenance, extension and replacement of existing 20 mm conduit support systems.
