Rittal CP6212.680 CP 120 intermediate hinge without height offset designed for pivoted connection of horizontal support profiles in industrial support arm systems.
£387.19
The Rittal CP 6212.680 is a robust CP 120 intermediate hinge without height offset designed for creating a vertically hinged connection between horizontal support sections within the Rittal CP support arm system. As part of the Rittal CP 120 range, it provides a flexible and reliable solution for industrial operator interface installations requiring pivoting support arm configurations.
This intermediate hinge allows horizontal support profiles to rotate and tilt, helping machine builders and automation engineers create ergonomic operator stations with adjustable positioning. The integrated rotation adjustment system enables controlled movement while maintaining a secure mechanical connection between support sections.
With a cast steel hinge construction, RAL 7035 finish and an adjustable swivel range of approximately 180°, the CP 6212.680 is suitable for demanding industrial environments where reliable operator panel positioning and support arm flexibility are required.
The Rittal CP 6212.680 intermediate hinge provides machine builders with a practical solution for creating movable operator interfaces. By allowing controlled rotation of horizontal support sections, it improves ergonomics and enables operators to position control equipment where it is most accessible.
Designed for use within Rittal CP 120 support arm systems, this hinge combines mechanical strength with adjustable movement, supporting reliable HMI and enclosure mounting solutions in modern industrial environments.
| Manufacturer | Rittal |
|---|---|
| Series | CP Support Arm Systems |
| Model | CP 6212.680 |
| Product type | Intermediate hinge CP 120 without height offset |
| Application | Pivoted connection of horizontal support profiles |
| Material | Cast steel |
| Concertina section material | Plastic |
| Colour | RAL 7035 / RAL 7024 |
| Rotating / tilting | Yes |
| Rotation angle / swivel area | approx. 180° |
| Packaging unit | 1 pc |
| Net weight | 7 kg |
| Gross weight | 7.18 kg |
| EAN | 4028177705623 |
The Rittal CP 6212.680 is used to create a vertically hinged connection between horizontal support sections within the Rittal CP 120 support arm system.
Yes, the intermediate hinge provides an adjustable swivel range of approximately 180°.
The intermediate hinge is manufactured from cast steel with a plastic concertina section.
The supply includes the concertina section, slotted discs and screws for rotation adjustment, adjusting screws, self-tapping screws and seals.
The CP 6212.680 belongs to the Rittal CP 120 support arm system range for industrial operator interface installations.
Rittal CP support arm systems provide reliable, flexible and ergonomic solutions for industrial operator interfaces, helping machine builders create durable automation installations.
