Rittal CP6212.780 wall-mounted hinge for CP 120 support arm systems with horizontal outlet without height offset and swivel mounting capability.
£328.14
The Rittal CP6212.780 is a heavy-duty wall-mounted hinge for the CP 120 support arm system designed for secure swivel mounting of industrial operating housings and support arms on vertical surfaces. As part of the versatile Rittal CP 120 support arm system, this horizontal outlet hinge without height offset provides a reliable mechanical connection for machine control panels and industrial operator interfaces.
This wall-mounted hinge enables flexible positioning of support arms while maintaining a compact installation arrangement without additional height offset. The robust construction and integrated adjustment features make it suitable for demanding automation, machine building and industrial control applications.
With a rotating and tilting design offering an adjustable approx. 180° swivel range, the CP6212.780 allows operators to position control enclosures ergonomically while providing a stable connection between the support arm and mounting surface.
The Rittal CP6212.780 wall-mounted hinge provides a dependable connection point for CP 120 support arm assemblies, allowing machine builders to create stable and ergonomic operator control solutions. Its horizontal outlet configuration without height offset helps maintain a compact and efficient installation layout.
Designed for industrial automation environments, the CP 120 support arm system offers modular flexibility for mounting HMIs, operating housings and control panels while maintaining reliable mechanical performance.
| Manufacturer | Rittal |
|---|---|
| Series | CP 120 Support Arm System |
| Model | CP6212.780 |
| Article number | 6212780 |
| Product type | Wall-mounted hinge |
| Outlet type | Horizontal outlet |
| Height offset | Without height offset |
| Application | Swivel mounting of support arms on vertical surfaces |
| Material | Cast steel |
| Concertina section | Plastic |
| Colour | RAL 7035 (hinge), RAL 7024 (concertina section) |
| Rotating/tilting | Yes |
| Rotation angle/swivel range | Approx. 180° |
| Net weight | 8 kg |
| Gross weight | 8.32 kg |
| Packaging unit | 1 pc |
| EAN | 4028177705616 |
The CP6212.780 is a wall-mounted hinge used for swivel mounting CP 120 support arm systems on vertical surfaces for industrial operating enclosures.
The CP6212.780 features a horizontal outlet without height offset for compact CP 120 support arm installations.
The wall-mounted hinge provides an approximate 180° rotation range, adjustable to a limited extent using slotted steel discs.
The wall-mounted hinge is manufactured from cast steel with a plastic concertina section.
The CP6212.780 is designed for use with the Rittal CP 120 support arm system.
Rittal CP support arm system components are widely used by machine builders and automation engineers to create reliable, ergonomic and flexible operator control solutions for modern industrial equipment.
