Why Choose the Rittal SK 3355.700 Display Frame?
The Rittal SK 3355.700 is a purpose-designed display frame for Blue e+ roof-mounted cooling units and the VX25 Blue e+ integration solution. It allows the cooling system's touch display to be relocated from the unit itself and positioned directly in the enclosure door for easier access during operation, monitoring and maintenance.
By moving the touch display to an optimum operator height, the display frame improves visibility and accessibility without compromising enclosure protection. The assembly is manufactured from durable plastic in RAL 7016 and is designed to maintain an IP54 protection rating when correctly installed.
The SK 3355.700 measures 316 × 118 × 27.5 mm (W × H × D) and is compatible with Rittal model numbers 3185.030 and 3185.730. It is supplied as a complete installation package including the display frame, blanking cover, 3 m RJ12 extension cable, assembly parts and sealing material.
Key Advantages
- Allows the Blue e+ touch display to be positioned in the enclosure door.
- Improves operator access by placing the display at an optimum working height.
- Designed for Blue e+ roof-mounted cooling units and VX25 Blue e+ integration solutions.
- Maintains an IP54 protection rating when correctly installed.
- Compact 316 × 118 × 27.5 mm format.
- Supplied with a 3 m RJ12 extension cable for display connection.
- Includes assembly parts and sealing material for straightforward installation.
Key Features
- Rittal display frame accessory.
- Designed for relocating the touch display to the enclosure door.
- Compatible with Rittal 3185.030 and 3185.730.
- Plastic construction.
- RAL 7016 colour.
- IP54 protection category to IEC 60529.
- Supplied with blanking cover.
- Includes RJ12 extension cable, 3 m.
- Includes assembly parts and sealing material.
- Supplied as 1 piece.
Convenient Operator Access for Blue e+ Cooling Systems
Relocating the touch display to the enclosure door allows operators and maintenance personnel to view cooling-unit information and access controls without needing to reach the roof-mounted unit itself. This can simplify routine monitoring, commissioning and servicing, particularly on tall enclosures or installations where the cooling unit is mounted above normal eye level.
The SK 3355.700 is designed as a dedicated Rittal system accessory, helping preserve a clean installation appearance and enclosure protection while providing the required mechanical mounting and electrical extension components for the display.
Typical Applications
- Rittal Blue e+ roof-mounted cooling unit installations.
- VX25 Blue e+ integration solutions.
- Industrial electrical control enclosures.
- Automation cabinets requiring accessible cooling-system controls.
- Enclosures where the roof-mounted display is above convenient operator height.
- Machine and production systems using Blue e+ enclosure climate control.
