Why Choose the Rittal SM6002.130 Pull-Out Keyboard with Integrated Trackball?
The Rittal SM6002.130 is a professional pull-out industrial keyboard with integrated trackball designed for machinery, control panels and operator interface applications. Featuring a German keyboard layout, 84 short-stroke keys and dedicated cursor keys, it provides a compact and practical input solution for industrial control environments.
The super-slimline keyboard incorporates an integrated 16 mm trackball, eliminating the need for a separate mouse and helping conserve valuable operator workstation space. Its pull-out mechanism positions the keyboard at a 10° angle when extended to support ergonomic operation, while the front handle also functions as a convenient handrest.
Manufactured from durable sheet steel with a powder-coated RAL 7035 front panel, the SM6002.130 provides IP65 protection at the front when sealed. Dual USB interfaces provide straightforward connection, while flexible installation options allow the keyboard to be integrated into suitably sized enclosure surfaces, front panels and compatible Rittal Comfort Panel or Optipanel systems.
Key Advantages
- Compact pull-out industrial keyboard with integrated trackball.
- German keyboard layout with 84 short-stroke keys and cursor keys.
- Integrated 16 mm trackball removes the need for a separate mouse.
- IP65 protection at the front when sealed for demanding industrial installations.
- 10° angled pull-out supports comfortable and ergonomic operation.
- Front handle doubles as a practical handrest.
- 2 × USB interfaces for keyboard and trackball connectivity.
- Suitable for integration into enclosure doors, side panels and operator housings.
Key Features
- Rittal SM pull-out keyboard.
- German keyboard layout.
- 84 short-stroke keys, IBM-AT compatible (MF2), including cursor keys.
- Integrated 16 mm trackball.
- 2 × USB interfaces.
- 10° pull-out angle for ergonomic working.
- Handle also functions as a handrest.
- IP65 front protection when sealed to IEC 60529.
- Sheet steel construction with powder-coated front panel.
- Suitable for direct installation into appropriately sized Rittal Comfort Panel and Optipanel systems.
Ergonomic Input Control for Industrial Operator Interfaces
Industrial machinery and automation systems frequently require reliable keyboard and pointer input without sacrificing valuable operator workstation space. The Rittal SM6002.130 combines both functions in one compact assembly, with an integrated trackball providing cursor control directly alongside the keyboard.
The pull-out design allows the keyboard to remain compact when not required and positions it at a 10° operating angle when extended. Combined with the handrest function of the handle and IP65 front protection when sealed, this makes the SM6002.130 a practical input solution for industrial human-machine interfaces and control stations.
Typical Applications
- Industrial control and operator stations.
- Human-machine interface installations.
- Machine control panels.
- Industrial PC installations.
- Manufacturing and production machinery.
- Process automation systems.
- Rittal Comfort Panel installations.
- Rittal Optipanel operator enclosures.
