Why Choose the Rittal SV 3582.000 E-Cu Busbar?
The Rittal SV 3582.000 is a high-quality flat E-Cu copper busbar designed for reliable electrical power distribution within industrial switchgear, control cabinets and compatible Rittal busbar systems. Manufactured from E-Cu F30 electrolytic copper, it provides excellent electrical conductivity and a robust current-carrying path for professional low-voltage distribution assemblies.
With a cross-section of 20 × 5 mm and a conductor area of approximately 99.1 mm², the SV 3582.000 is suitable for substantial industrial loads while retaining a compact flat profile. It is manufactured in accordance with DIN EN 13601 and is suitable for integration into the Rittal RiLine60 busbar system.
The busbar is supplied in a standard length of 2,400 mm and may be individually cut to the required length for specific panel configurations. Rittal specifies a current capacity of up to 319 A according to IEC and 230 A according to UL 508, making the SV 3582.000 a versatile solution for industrial power distribution and switchgear construction.
Key Advantages
- High-quality E-Cu F30 electrolytic copper busbar for industrial power distribution.
- 20 × 5 mm cross-section provides a compact and effective current-carrying conductor.
- Rated up to 319 A according to IEC.
- 2,400 mm standard length provides flexibility for larger electrical assemblies.
- May be individually cut to the required length for customised installations.
- Designed for integration with the Rittal RiLine60 busbar system.
Key Features
- Rittal SV E-Cu busbar.
- Manufactured from E-Cu F30 electrolytic copper.
- 20 mm width.
- 5 mm thickness.
- Approximately 99.1 mm² conductor cross-sectional area.
- 2,400 mm overall length.
- 319 A IEC current rating.
- 230 A UL 508 current rating.
- Manufactured in accordance with DIN EN 13601.
- Suitable for Rittal RiLine60 power distribution systems.
- May be individually cut to the required length.
Reliable Copper Busbar Power Distribution
Copper busbars provide a low-resistance and space-efficient method of distributing electrical power throughout industrial switchgear and control assemblies. The Rittal SV 3582.000 uses an E-Cu F30 copper conductor measuring 20 × 5 mm to provide dependable current distribution while supporting an organised and modular electrical panel layout.
Its compatibility with the Rittal RiLine60 system allows the busbar to be combined with suitable busbar supports, connection components and switching equipment to create integrated power distribution assemblies. The 2,400 mm standard length can also be cut to suit individual installation requirements, making it suitable for both standardised and customised panel designs.
Typical Applications
- Rittal RiLine60 busbar distribution systems.
- Industrial switchgear and power distribution panels.
- Main and sub-distribution electrical assemblies.
- Industrial control and automation cabinets.
- Machine and production-line power distribution.
- OEM switchgear and electrical panel building.
