Rittal SV9686.810 M10 connection set for Flat-PLS busbar systems, designed for securing components and connecting 50 x 10 mm flat copper busbars in power distribution assemblies.
£14.28
The Rittal SV9686.810 is a reliable M10 connection set for Flat-PLS busbar systems designed for securing top-mounted components and connecting copper busbars within Rittal power distribution assemblies. As part of the Rittal VX power distribution accessory range, it provides a dependable mechanical connection solution for industrial switchgear and low-voltage distribution systems.
This connection set is designed for attaching NH slimline fuse-switch disconnectors and NH slimline switch-disconnectors with 185 mm mounting distance or for connecting busbars. It is suitable for flat copper busbar systems with a 50 × 10 mm profile, supporting efficient assembly of modular power distribution components.
Featuring an M10 thread and supplied as a pack of 3 pcs, the Rittal SV9686.810 provides a practical fastening solution for professional switchgear construction and Flat-PLS busbar connection applications.
The Rittal SV9686.810 connection set provides a secure and practical method for connecting copper busbars and installing power distribution components within modular switchgear systems. Its M10 threaded connection design supports reliable mechanical fastening and efficient assembly.
Combined with Rittal Flat-PLS busbar systems, VX enclosure solutions and compatible distribution components, this accessory helps create safe, organised and service-friendly electrical installations.
| Manufacturer | Rittal |
|---|---|
| Series | VX / Flat-PLS power distribution accessories |
| Model | SV9686.810 |
| Product type | Connection set |
| Thread | M10 |
| Compatible busbar | Flat copper 50 × 10 mm |
| Number of busbars | 2 / 4 |
| Material | Sheet steel, zinc-plated |
| Packaging unit | 3 pcs |
| Net weight | 0.114 kg |
| Gross weight | 0.129 kg |
The SV9686.810 is an M10 connection set used for securing top-mounted components and connecting busbars in Rittal Flat-PLS power distribution systems.
The connection set is designed for flat copper busbar systems with a size of 50 × 10 mm.
The Rittal SV9686.810 uses an M10 thread for secure component and busbar connections.
The connection set is supplied as a pack of 3 pcs.
The SV9686.810 is suitable for securing NH slimline fuse-switch disconnectors, NH slimline switch-disconnectors and connecting compatible busbars.
Rittal power distribution accessories are trusted by panel builders and electrical engineers worldwide for reliable busbar connections, efficient assembly and professional switchgear construction.
