Rittal SZ 2570.500 earthing plate for compatible enclosure systems, providing a threaded earth connection and distribution to up to eight components through 6.3 mm flat-pin connectors.
£25.76
The Rittal SZ 2570.500 is a compact earthing plate for industrial electrical enclosures, designed to provide a convenient central connection point for protective earthing and equipotential bonding. As part of the Rittal SZ system accessories range, it allows an earthing cable to be screw-fastened to a threaded bolt and distributed to multiple enclosure components using 6.3 mm flat-pin connectors.
The earthing plate provides a practical way to organise multiple earth connections within compatible Rittal enclosure systems. A single earthing cable can be connected to the threaded bolt, with the earth connection then distributed to up to eight components through 6.3 mm flat-pin connectors.
The SZ 2570.500 is suitable for installation in Comfort Panel, Optipanel, VX, TS, VX SE and PC enclosure systems. Assembly parts are included, allowing the earthing plate to be installed as part of the enclosure's internal earthing arrangement.
The Rittal SZ 2570.500 provides a convenient method of distributing an enclosure's protective earth connection. The main earthing cable is attached to the threaded bolt, while additional earth connections can be distributed through the integrated 6.3 mm flat-pin connection points.
Supporting up to eight connected components, the earthing plate helps simplify internal enclosure wiring and provides an organised approach to protective bonding. Its compatibility with several Rittal enclosure families makes it suitable for a wide range of industrial control and electrical panel applications.
| Manufacturer | Rittal |
|---|---|
| Series | SZ System Accessories |
| Model | SZ 2570.500 |
| Alternative article number | 2570500 |
| Product type | Earthing plate |
| Application | Protective earthing and equipotential bonding |
| Main connection | Threaded bolt |
| Component connections | 6.3 mm flat-pin connectors |
| Maximum number of component connections | 8 |
| Suitable enclosure types | Comfort Panel, Optipanel, VX, TS, VX SE, PC |
| Supply includes | Assembly parts |
| Packaging unit | 1 pc |
| Net weight | 0.038 kg |
| Gross weight | 0.053 kg |
| Customs tariff number | 73269098 |
| EAN | 4028177388253 |
| ETIM 9 | EC002623 |
| ETIM 8 | EC002623 |
| ECLASS 8.0 | 27189264 |
The Rittal SZ 2570.500 is an earthing plate used to establish and distribute protective earth connections within compatible Rittal enclosure systems.
The earthing plate can distribute the earth connection to up to eight components using 6.3 mm flat-pin connectors.
The main earthing cable can be screw-fastened to the threaded bolt on the earthing plate.
The component connections use 6.3 mm flat-pin connectors.
The earthing plate is suitable for Comfort Panel, Optipanel, VX, TS, VX SE and PC enclosure systems.
Rittal SZ system accessories provide dependable solutions for enclosure earthing, equipotential bonding and internal electrical installation across industrial control and automation systems.
