Why Choose the Rittal TS 4134.000 Angle Piece?
The Rittal TS 4134.000 is a versatile angle piece designed for assembling punched rails and mounting surfaces with a 45° incline within compatible Rittal enclosure and rail systems. It provides a practical mounting solution for creating angled installation surfaces in industrial electrical enclosures.
The angle piece is manufactured from die-cast zinc and supplied with a plastic insulating piece, providing two standard mounting options. It can either be mounted conductively to the supporting structure or electrically insulated from the mounting surface, giving panel builders greater flexibility when configuring enclosure interiors.
The TS 4134.000 is compatible with Rittal VX, TS and VX SE enclosure systems and can be installed on a range of system sections, brackets, spacers and quick-assembly blocks. Supplied as a pack of 12 pieces with the required mounting components, it is well suited to professional enclosure building and industrial automation applications.
Key Advantages
- Purpose-designed angle piece for 45° inclined mounting.
- Suitable for assembling punched rails and mounting surfaces within compatible Rittal systems.
- Die-cast zinc construction provides a robust mounting component.
- Includes an insulating piece for flexible electrical isolation.
- Two standard mounting options: conductive or insulated from the mounting surface.
- Compatible with VX, TS and VX SE enclosure systems.
- Supplied in a practical 12-piece pack with mounting hardware.
Key Features
- Rittal TS 4134.000 angle piece.
- 45° inclined mounting for punched rails and mounting surfaces.
- Die-cast zinc angle piece.
- Plastic insulating piece.
- Conductive or insulated mounting options.
- Includes insulating screw, two assembly screws and M8 threaded block.
- Suitable for VX, TS and VX SE enclosure systems.
- Can be mounted on horizontal and vertical enclosure sections.
- Suitable for system chassis, brackets, spacers and quick-assembly blocks.
- Compatible with rectangular system punching of 12.5 × 10.5 mm.
- 12 pieces per pack.
Flexible 45° Mounting for Rittal Enclosure Systems
The Rittal TS 4134.000 provides a straightforward way to create 45° angled mounting positions for punched rails and mounting surfaces. This is particularly useful when electrical and control components need to be positioned at an angle to improve accessibility, equipment arrangement or use of available enclosure space.
The supplied insulating components allow the mounting arrangement to be configured either with a conductive connection to the supporting structure or electrically isolated from the mounting surface. The angle piece can be installed across a wide range of Rittal enclosure sections and system components, supporting flexible internal enclosure configurations.
Typical Applications
- Rittal VX enclosure systems.
- Rittal TS enclosure systems.
- Rittal VX SE enclosure systems.
- Angled mounting of punched rails.
- Angled mounting surfaces for electrical components.
- Industrial control cabinets.
- Electrical panel building and automation systems.
- Internal enclosure component positioning.
