nVent HOFFMAN NOX06B0E1U00009 is a 230 V outdoor vertical enclosure air conditioner with approximately 555 W cooling capacity, stainless steel construction and IP55 / NEMA Type 4X environmental protection.
£3,491.00
The nVent HOFFMAN NOX06B0E1U00009 is a compact E-NOX outdoor vertical enclosure air conditioner designed to provide reliable closed-loop cooling for electrical and electronic equipment installed in demanding environments. Part of the nVent HOFFMAN NOX06 series, it combines effective thermal management with stainless steel construction and a compact vertical mounting format.
Designed specifically for outdoor enclosure applications, the NOX06B0E1U00009 features IP55 protection and a NEMA Type 4X stainless steel configuration. Its closed-loop cooling arrangement separates the enclosure's internal air from the surrounding environment, helping protect sensitive electrical components while removing internally generated heat.
Operating from a 230 V AC supply, the unit provides a published cooling capacity of approximately 555 W and cabinet airflow of 305 m³/h. Measuring 640 mm high, 316 mm wide and 240 mm deep, it provides a space-efficient cooling solution for outdoor industrial enclosures requiring dependable environmental protection.
Outdoor electrical enclosures can be exposed to elevated ambient temperatures, moisture, dust and other environmental conditions while internal electrical equipment continues to generate heat. A closed-loop air conditioner removes this heat while maintaining separation between internal enclosure air and the outside environment, helping sensitive electronic and control equipment operate within suitable temperature limits.
The nVent HOFFMAN E-NOX range is engineered for outdoor thermal management, and the NOX06B0E1U00009 combines stainless steel construction, IP55 protection and a NEMA Type 4X configuration with a compact vertical design. This makes it particularly suitable for industrial installations where environmental resistance and dependable enclosure cooling are both required.
| Country of Manufacture | Italy |
|---|---|
| Manufacturer | nVent HOFFMAN |
| Series | E-NOX / NOX06 |
| Model | NOX06B0E1U00009 |
| Product type | Outdoor vertical enclosure air conditioner |
| Cooling capacity | approx. 555 W |
| Rated voltage | 230 V AC |
| Frequency | 50 / 60 Hz |
| Nominal current | 2.3 A |
| Power consumption | 380 W at L35/L35 |
| Power consumption at L35/L50 | 450 W |
| Inrush current | 10.9 A |
| Recommended T fuse | 6 A |
| Cabinet air fan capacity | 305 m³/h |
| Noise level | 65 dB(A) |
| Material | Stainless steel |
| Ingress protection | IP55 |
| NEMA rating | Type 4X stainless steel configuration |
| Mounting | Vertical |
| Height | 640 mm |
| Width | 316 mm |
| Depth | 240 mm |
| Weight | 24 kg |
| Maximum outdoor temperature | 55 °C |
| Approvals | UL Listed, CE, UKCA |
| EAN / Barcode | 8713574423961 |
The NOX06B0E1U00009 is an outdoor enclosure air conditioner designed to remove heat from electrical and electronic cabinets while maintaining closed-loop separation between enclosure air and the surrounding environment.
The NOX06B0E1U00009 provides a published cooling capacity of approximately 555 W, making it suitable for compatible small and medium enclosure cooling requirements.
The unit is designed for a 230 V AC supply and supports 50/60 Hz operation.
Yes. The unit is specifically designed for outdoor enclosure cooling and features stainless steel construction with IP55 and NEMA Type 4X protection for demanding environments.
The NOX06B0E1U00009 measures 640 mm high, 316 mm wide and 240 mm deep and weighs approximately 24 kg.
nVent HOFFMAN E-NOX cooling units provide dependable closed-loop thermal management for outdoor electrical and electronic enclosures, with the NOX06B0E1U00009 combining compact cooling performance, stainless steel construction and IP55 / NEMA Type 4X environmental protection.
