Why Choose the ABB A41 113-100 Energy Meter?
The ABB A41 113-100 is a compact and accurate single-phase direct-connected electricity meter designed for active energy measurement in commercial, industrial and building-services installations. As part of the ABB A41 energy meter series, it combines direct measurement up to 80 A with a clear backlit digital display and integrated M-Bus communication.
Designed for direct connection to single-phase circuits, the A41 113-100 measures active energy with Class B (Class 1) accuracy. It also displays useful instrumentation values including power, current, line-to-neutral voltage and frequency, allowing the meter to provide both accumulated energy information and operating data for the monitored circuit.
The meter operates across a wide 57.7–288 V AC voltage range and incorporates an M-Bus interface for remote energy-data collection. A configurable output can be used for energy pulses or alarm signalling, while up to 25 alarm conditions can be configured. Its four-module DIN-rail format, infrared interface and IEC and MID approvals make it well suited to professional energy-monitoring and sub-metering installations.
Key Advantages
- Compact single-phase direct-connected energy meter for professional installations.
- Direct measurement up to 80 A without requiring an external current transformer.
- Class B (Class 1) active energy accuracy for dependable consumption monitoring.
- Integrated M-Bus communication for remote meter reading and system integration.
- Measures and displays active energy, power, current, voltage and frequency.
- Configurable output can provide energy pulses or alarm signalling.
- Supports up to 25 configurable alarm conditions.
- IEC approved and MID approved and verified for compliant energy-metering applications.
- Compact four-module DIN-rail format simplifies installation in distribution boards.
Key Features
- ABB A41 energy meter series.
- Single-phase direct-connected electricity meter.
- 80 A maximum direct-connected current.
- 57.7–288 V AC voltage range.
- 50–60 Hz operating frequency.
- Class B (Class 1) active energy accuracy.
- Active electrical energy measurement.
- Instrumentation values for power, current, voltage and frequency.
- Integrated M-Bus communication.
- Infrared interface for compatible system integration.
- One configurable output for pulse or alarm functions.
- Up to 25 configurable alarm conditions.
- Large backlit digital display with up to seven digits.
- Single-tariff energy measurement.
- Compact four-module DIN-rail construction.
Reliable Single-Phase Energy Monitoring
Direct-connected energy meters such as the ABB A41 113-100 allow electrical consumption to be measured without external current transformers on suitable circuits. With a maximum direct current of 80 A, the meter provides a practical solution for monitoring single-phase loads while its instrumentation functions provide additional visibility of current, voltage, power and frequency.
Integrated M-Bus communication enables measured energy and instrumentation data to be incorporated into compatible building-management and energy-monitoring systems. The configurable pulse or alarm output and extensive alarm functionality further support automated monitoring, helping operators identify predefined electrical conditions and analyse energy consumption across commercial and industrial installations.
Typical Applications
- Commercial building energy monitoring.
- Single-phase electrical sub-metering.
- Industrial control and distribution panels.
- Building management systems using M-Bus communication.
- Tenant and departmental electricity monitoring.
- Lighting and building-services circuits.
- Energy efficiency and consumption analysis.
- DIN-rail distribution boards requiring direct energy measurement.
