DI372AV6DB0XX – 3 DGT DC-METER, 72X72, 48VAC

Q: What type of input does this panel meter support?

The DI372AV6DB0XX supports DC input for use as either an ammeter or voltmeter.

Q: What current range can the DI372AV6DB0XX measure?

This model can measure DC current up to 1 A.

Q: What power supply does this model require?

The Carlo Gavazzi DI372AV6DB0XX requires a 48 V AC power supply.

Carlo Gavazzi DI372AV6DB0XX digital DC ammeter or voltmeter with 3-digit display, 72 x 72 mm front panel mounting, DC input measurement and 48 V AC power supply.

SKU: DI372AV6DB0XXMPN: DI372AV6DB0XX

List Price £124.29 ex VAT

Your Price (ex VAT)

£124.29

Manufacturer Lead Time Please contact us for a delivery time before you order

Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Quantity:

SUBTOTAL (EX VAT) £124.29

Trade pricing is personalised to your account

Manufacturer Lead Time

£124.29

Why Choose the Carlo Gavazzi DI372AV6DB0XX DC Panel Meter?

The Carlo Gavazzi DI372AV6DB0XX is a reliable digital DC ammeter and voltmeter designed for accurate electrical indication in industrial control panels, switchboards and automation systems. As part of the Carlo Gavazzi DI3-72 AV6 series, it provides clear local monitoring of DC current and voltage values in a compact panel-mounted format.

This microprocessor-based meter features a 3-digit display, selectable input ranges and a standard 72 x 72 mm front panel mounting design. It is suitable for engineers, OEMs and panel builders who need a dependable instrument for monitoring DC circuits, power supplies and equipment status.

With a 48 V AC power supply, DC current measurement up to 1 A and selectable voltage ranges up to 500 V DC, the DI372AV6DB0XX provides flexible measurement capability for a wide range of industrial electrical applications.

Key Advantages

Compact digital DC ammeter or voltmeter for industrial panels.
3-digit display read-out for clear local indication.
DC input measurement for current and voltage applications.
Current measurement up to 1 A.
Selectable voltage ranges up to 500 V DC.
48 V AC power supply for control panel installations.

Key Features

Carlo Gavazzi DI3-72 AV6 digital panel meter series.
3-digit meter display.
DC input type for current or voltage measurement.
Up to 1 A current input.
Voltage ranges up to 20 V, 100 V, 200 V and 500 V DC.
48 V AC auxiliary power supply.
72 x 72 mm front panel mounting.
Suitable for control panels, switchboards and OEM equipment.

Reliable DC Monitoring for Industrial Panels

Digital panel meters such as the Carlo Gavazzi DI372AV6DB0XX allow operators and maintenance engineers to view important DC electrical values directly from the front of a control cabinet. This helps support commissioning, troubleshooting and routine monitoring of industrial systems.

The selectable current and voltage measurement options make this meter suitable for a broad range of DC applications, including power supply monitoring, machine control systems, battery-related equipment and electrical distribution panels.

Typical Applications

Industrial control panels and automation cabinets.
DC power supply monitoring.
Electrical switchboards and distribution panels.
Machine control and OEM equipment.
Battery and charger system indication.
Process control and plant instrumentation.

Technical Specifications

Tick the specs you need, then view products that match.

Measurement Functions	Current, Voltage
Device Type	Ammeter / voltmeter
Phase	DC
Cut-Out Size (mm)	68 × 68 mm
Signal / Input Range	DC V / A
Coil / Supply Voltage	48 V AC
Display	LED (7-segment)
Manufacturer	Carlo Gavazzi
Series	DI3-72 AV6
Model	DI372AV6DB0XX
Product type	Digital DC ammeter / voltmeter
Meter type	Meter
Display read-out	3 digit
Input type	DC
Current input	Up to 1 A
Voltage input	Up to 20 V, 100 V, 200 V and 500 V DC
Power supply	48 V AC
Mounting type	72 x 72 mm front panel mounting
Measurement function	Ammeter or voltmeter
Display format	Digital panel indicator
Application	DC electrical measurement and indication

Frequently Asked Questions

What is the Carlo Gavazzi DI372AV6DB0XX used for?

It is used to measure and display DC current or DC voltage values in industrial control panels, switchboards and automation systems.

What type of input does this panel meter support?

The DI372AV6DB0XX supports DC input for use as either an ammeter or voltmeter.

What current range can the DI372AV6DB0XX measure?

This model can measure DC current up to 1 A.

What voltage ranges are available?

The meter supports selectable voltage measurement ranges up to 20 V, 100 V, 200 V and 500 V DC.

What power supply does this model require?

The Carlo Gavazzi DI372AV6DB0XX requires a 48 V AC power supply.

Trusted by Industrial Panel Builders Worldwide

Carlo Gavazzi digital panel meters are widely used by electrical engineers, OEMs and panel builders for dependable measurement, clear indication and reliable performance in industrial control and power monitoring applications.

Measurement Functions	Current, Voltage
Device Type	Ammeter / voltmeter
Phase	DC
Cut-Out Size (mm)	68 × 68 mm
Signal / Input Range	DC V / A
Coil / Supply Voltage	48 V AC
Display	LED (7-segment)
Manufacturer	Carlo Gavazzi
Series	DI3-72 AV6
Model	DI372AV6DB0XX
Product type	Digital DC ammeter / voltmeter
Meter type	Meter
Display read-out	3 digit
Input type	DC
Current input	Up to 1 A
Voltage input	Up to 20 V, 100 V, 200 V and 500 V DC
Power supply	48 V AC
Mounting type	72 x 72 mm front panel mounting
Measurement function	Ammeter or voltmeter
Display format	Digital panel indicator
Application	DC electrical measurement and indication
