Why Choose the Lovato DMG800 Digital Multimeter?
The Lovato DMG800 is an expandable flush-mounted multifunction digital multimeter and electrical network analyser designed for detailed monitoring of single-phase and three-phase power systems. Its high-resolution graphic display, accurate True RMS measurement and advanced harmonic analysis make it suitable for industrial switchboards, energy-management systems and power-quality monitoring applications.
The DMG800 measures voltage, current, active power, reactive power, apparent power, frequency, power factor and electrical energy. It also provides individual harmonic analysis up to the 31st harmonic order, helping engineers identify waveform distortion caused by variable speed drives, power supplies and other non-linear electrical loads.
Designed for external 1 A or 5 A current transformers, the meter provides Class 0.5S active energy measurement accuracy and can be expanded with compatible Lovato EXP modules. Please note that the Lovato DMG800 is listed as out of catalogue. Contact LED Controls to check availability or identify a suitable current replacement.
Key Advantages
- Expandable multifunction electrical network analyser.
- Clear 128 × 80 pixel graphic LCD.
- Accurate True RMS voltage and current measurement.
- Individual harmonic analysis up to the 31st order.
- Supports external 1 A or 5 A current transformers.
- Class 0.5S active energy measurement accuracy.
- Expandable using compatible Lovato EXP modules.
- Suitable for industrial energy monitoring and power analysis.
Key Features
- Lovato DMG800 expandable digital multimeter.
- Flush-mounted panel design.
- 128 × 80 pixel graphic LCD display.
- Multilingual interface in Italian, English, French, Spanish and Portuguese.
- True RMS voltage and current measurement.
- Active, reactive and apparent power monitoring.
- Active and reactive electrical energy measurement.
- Frequency and power factor monitoring.
- Individual current harmonic analysis up to the 31st order.
- Compatible with 1 A and 5 A current transformer secondary outputs.
- Expandable with optional communication and I/O modules.
- Wide-range AC and DC auxiliary supply.
Advanced Electrical and Harmonic Monitoring
The Lovato DMG800 provides detailed visibility of electrical network performance, enabling engineers to monitor energy consumption, power demand, loading conditions and system efficiency. Its True RMS measurement technology supports reliable monitoring even when distorted waveforms and non-linear electrical loads are present.
Harmonic analysis up to the 31st order helps identify power-quality problems that may contribute to overheating, equipment malfunction or reduced electrical-system efficiency. Optional EXP modules allow the base instrument to be adapted with communication interfaces and programmable input or output functions.
Typical Applications
- Industrial switchboards and distribution panels.
- Motor control centres.
- Manufacturing and process installations.
- Commercial building energy monitoring.
- Generator and transformer monitoring.
- Power-quality and harmonic analysis.
- Energy-management and supervisory systems.
- Electrical load and demand monitoring.
