Lovato BF0040L024 BF00 series control relay with 24 V DC low-consumption coil, 4 poles, 4NO contacts, screw terminals and DIN rail or screw mounting for industrial automation control circuits.
£111.14
The Lovato BF0040L024 is a compact and reliable low-consumption DC control relay designed for industrial automation, electrical control panels and auxiliary switching applications. Part of the Lovato BF series, this relay features a 24V DC low-consumption coil and four normally open contacts (4NO) for dependable control circuit operation.
Designed for machine builders, OEM manufacturers and automation engineers, the BF0040L024 provides efficient switching performance while reducing control power requirements. Its compact construction, DIN rail compatibility and robust electrical characteristics make it suitable for modern industrial control systems.
The relay features a 24V DC low-consumption coil, 4-pole normally open contact configuration and flexible mounting options including screw fixing and 35mm DIN rail installation. It is engineered for reliable operation in industrial automation, signalling and electrical control applications.
Control relays provide an important interface between control signals and electrical switching circuits, allowing industrial equipment to operate efficiently and safely. The Lovato BF0040L024 delivers dependable switching performance for automation systems, machinery and electrical control installations.
Its low-consumption 24V DC coil helps optimise control panel power usage, while the four normally open contacts provide flexible circuit management for OEM equipment and industrial applications.
| Voltage | 24 V |
|---|---|
| Phase | Three Phase |
| Series | BF00 |
| Product designation | Auxiliary contactor |
| Product type | Control relay with AC and DC control circuit |
| Coil type | DC coil, low consumption |
| Rated coil voltage | 24 V DC |
| Number of poles | 4 |
| Built-in auxiliary contacts | 4NO |
| Conventional free air thermal current Ith | 10 A |
| Maximum operating current | 1.9 A |
| Auxiliary contact rating | A600 - P600 |
| Rated insulation voltage Ui | 690 V |
| Rated impulse withstand voltage Uimp | 6 kV |
| Operational frequency | 25 to 400 Hz |
| Terminal type | Screw connection |
| Terminal protection | IP20 when properly wired |
| Mounting type | 35 mm DIN rail or screw mounting |
| Width | approx. 45 mm |
| Height | approx. 81 mm |
| Package dimensions | 93 x 48 x 110 mm |
| Package volume | 491.04 cm³ |
| Weight | approx. 502 g |
| Operating temperature | -50 to +70 °C |
| Storage temperature | -60 to +80 °C |
| Maximum altitude | 3000 m |
| Mechanical durability | up to 20,000,000 cycles |
| EAN | 8013975167823 |
| Certifications | CCC, EAC, cULus |
| Standards | IEC/EN 60947-1, IEC/EN 60947-5-1, UL 60947-1, UL 60947-5-1, CSA C22.2 No. 60947-1, CSA C22.2 No. 60947-5-1 |
| HS Code | 85365080 |
The BF0040L024 is a control relay used for switching and controlling electrical circuits in industrial automation and control panel applications.
The relay uses a 24V DC low-consumption coil designed for industrial control circuits.
The relay includes four normally open contacts (4NO) across four poles for flexible switching control.
Yes, the Lovato BF0040L024 supports installation using a standard 35mm DIN rail or screw mounting.
This relay is commonly used in industrial automation panels, machinery control systems and electrical switching applications.
Lovato BF series control relays are widely used in industrial automation and electrical control systems where efficient operation, reliable switching and compact installation are required.
