Lovato 11B1250424220 four-pole industrial power contactor with 1250 A AC-1 rating and 220–230 V AC control coil for industrial power switching applications.
£9,863.58
The Lovato 11B1250424220 is a heavy-duty four-pole power contactor engineered for dependable switching of exceptionally high-current industrial electrical loads. Part of the robust Lovato B1250 contactor series, this model provides an IEC AC-1 operating current rating of 1250 A and features a 220–240 V AC, 50/60 Hz operating coil.
Designed for demanding industrial power-control applications, the B1250 contactor combines substantial switching capacity with reliable mechanical and electrical performance. Its four-pole configuration enables simultaneous control of four conductors, while the integrated 2NO + 4NC auxiliary contacts support signalling, electrical interlocking and control-system feedback.
With a conventional free-air thermal current of 1250 A at temperatures up to 40°C, a rated insulation voltage of 1000 V and an impulse withstand voltage of 8 kV, the 11B1250424220 is suitable for high-power switchboards, industrial heating systems, energy infrastructure and heavy process machinery.
Power contactors such as the Lovato 11B1250424220 allow high-current industrial loads to be switched using a lower-power electrical control circuit. Its four-pole design enables multiple conductors to be controlled together, making it suitable for three-phase systems requiring neutral switching and other multi-pole power-control arrangements.
The integrated auxiliary contacts provide status indication, electrical interlocking and feedback to automation equipment. Combined with its high AC-1 rating, substantial making and breaking capacities and robust construction, the B1250 contactor supports dependable operation in heavy industrial power systems.
| Voltage | 230 V |
|---|---|
| Phase | Three Phase |
| IP Rating | IP00 |
| Series | B1250 |
| Product type | Four-pole power contactor |
| Rated thermal current (Ith AC-1) | 1250 A |
| Operational voltage | up to 690 V AC |
| Control coil voltage | 220–230 V AC |
| Number of poles | 4 |
| Auxiliary contacts | 2NO + 4NC |
| Operational frequency | 25–400 Hz |
| Protection rating | IP00 |
| Mounting type | Screw mounting |
| Mechanical life | 5,000,000 operations |
| Electrical life | 700,000 operations |
| Operating temperature | -50 °C to +70 °C |
| Weight | approx. 57.5 kg |
It is used for switching high-current four-pole electrical loads in industrial power-distribution, heating, machinery and automation systems.
The contactor has a conventional free-air thermal and IEC AC-1 operating current rating of 1250 A at temperatures up to 40°C.
The operating coil is designed for a 220–240 V AC, 50/60 Hz control supply.
The 11B1250424220 has four main power poles, allowing four conductors to be switched simultaneously.
Yes. It includes 2 normally open and 4 normally closed auxiliary contacts for signalling, feedback and electrical interlocking.
Lovato Electric B1250 contactors provide the high current capacity, robust construction and dependable switching performance required by industrial panel builders, system integrators and electrical engineers.{ "@context": "https://schema.org/", "@type": "Product", "name": "Lovato 11B1250424220 B1250 Four-Pole Power Contactor 1250A", "sku": "11B1250424220", "mpn": "11B1250424220", "brand": { "@type": "Brand", "name": "Lovato Electric" }, "category": "Power Contactors", "description": "Lovato 11B1250424220 B1250 four-pole power contactor with a 1250 A AC-1 rating, 220–240 V AC coil and integrated 2NO plus 4NC auxiliary contacts for heavy-duty industrial power switching.", "additionalProperty": [ { "@type": "PropertyValue", "name": "AC-1 operating current", "value": "1250 A at 40°C" }, { "@type": "PropertyValue", "name": "Control coil voltage", "value": "220–240 V AC" }, { "@type": "PropertyValue", "name": "Number of poles", "value": "4" }, { "@type": "PropertyValue", "name": "Auxiliary contacts", "value": "2NO + 4NC" }, { "@type": "PropertyValue", "name": "Rated insulation voltage", "value": "1000 V" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the Lovato 11B1250424220 used for?", "acceptedAnswer": { "@type": "Answer", "text": "It is used for switching high-current four-pole electrical loads in industrial power-distribution, heating, machinery and automation systems." } }, { "@type": "Question", "name": "What is the current rating of this contactor?", "acceptedAnswer": { "@type": "Answer", "text": "The contactor has a conventional free-air thermal and IEC AC-1 operating current rating of 1250 A at temperatures up to 40°C." } }, { "@type": "Question", "name": "What control voltage does the contactor require?", "acceptedAnswer": { "@type": "Answer", "text": "The operating coil is designed for a 220–240 V AC, 50/60 Hz control supply." } }, { "@type": "Question", "name": "How many main poles does this contactor have?", "acceptedAnswer": { "@type": "Answer", "text": "The 11B1250424220 has four main power poles, allowing four conductors to be switched simultaneously." } }, { "@type": "Question", "name": "Does the contactor include auxiliary contacts?", "acceptedAnswer": { "@type": "Answer", "text": "Yes. It includes 2 normally open and 4 normally closed auxiliary contacts for signalling, feedback and electrical interlocking." } } ] }
