Lovato 11B250L0060C48 three-pole industrial contactor with integrated G495 mechanical latch, 265A AC3 operational current rating and 60V AC/DC universal control coil for industrial automation and motor control systems.
£2,205.13
The Lovato 11B250L0060C48 is a heavy-duty three-pole industrial power contactor engineered for reliable switching of high-current electrical loads in industrial motor control, automation and power distribution systems. As part of the proven Lovato B250 contactor series, this version is supplied with a factory-fitted G495 mechanical latch for applications requiring maintained switching.
The contactor incorporates a universal 60 V AC/DC operating coil together with a 48 V DC mechanical latch. Once energised, the mechanical latch holds the contactor in position without continuous coil power, helping reduce energy consumption while maintaining reliable circuit operation.
With an IEC AC-3 operational current rating of 265 A, a 350 A AC-1 thermal current rating and three normally open main poles, the 11B250L0060C48 is ideal for switching large motors, industrial drives and high-current power circuits.
Mechanically latched contactors remain in their selected operating position after the initial control signal has been removed. This reduces continuous control power consumption while ensuring critical loads remain energised until a deliberate release command is applied.
The Lovato 11B250L0060C48 combines high-current switching capability with a factory-installed G495 mechanical latch, making it ideal for industrial motor control centres, power distribution equipment and automation systems requiring maintained switching.
| Power | 140 kW |
|---|---|
| Current | 350 A |
| Voltage | 60 V |
| Phase | Three Phase |
| Series | B250 Contactors |
| Product type | Three-pole contactor with mechanical latch |
| Operational current (AC1) | 350 A |
| Operational current (AC3 at 400 V) | 265 A |
| Operational current (AC4 at 400 V) | 92 A |
| Rated operational power AC3 at 400 V | 140 kW |
| Control coil voltage | 60 V AC/DC |
| Mechanical latch voltage | 48 V DC |
| Number of poles | 3 |
| Contact configuration | 3 NO |
| Type of coil | AC/DC universal coil |
| Insulation voltage | 690 V |
| Mounting type | Screw mounting |
| Terminal type | Bolt connection |
| Package dimensions | approx. 260 × 148 × 227 mm |
| Weight | approx. 10 kg |
| EAN | 8013975067505 |
| Compliance | IEC/EN 60947-1, IEC/EN 60947-4-1, UL 60947-1, UL 60947-4-1, CSA C22.2 n° 60947-1, CSA C22.2 n° 60947-4-1 |
It is designed for switching high-current three-phase electrical loads in industrial motor control, automation and power distribution systems.
The contactor has a 350 A AC-1 thermal current rating and a 265 A AC-3 operational current rating.
The electronically controlled operating coil is rated for 60 V AC/DC.
Yes. It is supplied with a factory-fitted G495 mechanical latch operating from 48 V DC.
The Lovato 11B250L0060C48 features three normally open (3NO) main power poles for switching three-phase circuits.
Lovato B250 mechanically latched contactors are trusted by electrical engineers, machine builders and panel manufacturers for dependable high-current switching, long service life and reliable maintained-contact operation.{ "@context": "https://schema.org/", "@type": "Product", "name": "Lovato 11B250L0060C48 Three-Pole Mechanically Latched Power Contactor 265 A", "sku": "11B250L0060C48", "mpn": "11B250L0060C48", "gtin13": "8013975067505", "brand": { "@type": "Brand", "name": "Lovato Electric" }, "category": "Mechanically Latched Power Contactors", "description": "Lovato 11B250L0060C48 three-pole industrial power contactor with 265 A AC-3 rating, 60 V AC/DC operating coil and factory-fitted G495 48 V DC mechanical latch for industrial motor control and power switching.", "additionalProperty": [ { "@type": "PropertyValue", "name": "AC-3 operational current", "value": "265 A" }, { "@type": "PropertyValue", "name": "Operating coil voltage", "value": "60 V AC/DC" }, { "@type": "PropertyValue", "name": "Mechanical latch voltage", "value": "48 V DC" }, { "@type": "PropertyValue", "name": "Number of poles", "value": "3" }, { "@type": "PropertyValue", "name": "Rated insulation voltage", "value": "1000 V" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the Lovato 11B250L0060C48 used for?", "acceptedAnswer": { "@type": "Answer", "text": "It is designed for switching high-current three-phase electrical loads in industrial motor control, automation and power distribution systems." } }, { "@type": "Question", "name": "What current rating does this contactor support?", "acceptedAnswer": { "@type": "Answer", "text": "The contactor has a 350 A AC-1 thermal current rating and a 265 A AC-3 operational current rating." } }, { "@type": "Question", "name": "What control voltage does the operating coil require?", "acceptedAnswer": { "@type": "Answer", "text": "The electronically controlled operating coil is rated for 60 V AC/DC." } }, { "@type": "Question", "name": "Does this contactor include a mechanical latch?", "acceptedAnswer": { "@type": "Answer", "text": "Yes. It is supplied with a factory-fitted G495 mechanical latch operating from 48 V DC." } }, { "@type": "Question", "name": "How many main poles does the contactor have?", "acceptedAnswer": { "@type": "Answer", "text": "The Lovato 11B250L0060C48 features three normally open (3NO) main power poles for switching three-phase circuits." } } ] }
