Lovato 11BG0040A110 industrial control relay with 110 V AC coil and 4NO auxiliary contacts, designed for industrial automation and machine control applications.
£37.46
The Lovato 11BG0040A110 is a compact and dependable industrial control relay with an AC coil designed for electrical automation, control panels and industrial switching applications. As part of the reliable Lovato BG series, this relay provides efficient switching performance for machine control systems and low-voltage industrial installations.
Featuring a 110 V AC 50/60 Hz coil and a 4NO contact configuration, the Lovato 11BG0040A110 is designed for controlling auxiliary circuits and automation functions where reliable operation and long service life are essential. Its compact construction allows simple integration into electrical cabinets using screw terminals and 35 mm DIN rail mounting.
With four normally open contacts and a 10 A current rating, this Lovato control relay is suitable for industrial machinery, automation equipment, motor control panels and electrical distribution systems requiring dependable auxiliary switching.
Control relays such as the Lovato 11BG0040A110 provide a practical solution for switching auxiliary circuits, controlling automation signals and managing electrical loads in industrial environments. They help maintain reliable separation between control systems and switched circuits while improving overall system flexibility.
The Lovato BG series is developed for panel builders, machine manufacturers and automation professionals requiring compact, reliable and easy-to-install components for modern electrical control applications.
| Current | 00.40 A |
|---|---|
| Voltage | 110 V |
| Phase | Three Phase |
| IP Rating | IP20 |
| Series | BG Series |
| Product type | Control relay |
| Number of poles | 4 |
| Auxiliary contact configuration | 4NO |
| Coil type | AC coil 50/60Hz |
| Rated coil voltage | 110 V AC |
| Rated thermal current | 10 A AC1 |
| Maximum operating current | 6 A |
| Rated insulation voltage | 690 V |
| Rated impulse withstand voltage | 6 kV |
| Mounting type | Screw / DIN rail 35 mm |
| Terminal type | Screw terminals |
| Protection rating | IP20 |
| Mechanical endurance | 20 million cycles |
| Operating temperature | -50 °C to +70 °C |
| Dimensions (H × W × D) | approx. 60 × 45 × 60 mm |
| Weight | approx. 179 g |
| Standards | IEC/EN 60947-1, IEC/EN 60947-5-1, UL 60947-1, UL 60947-5-1 |
| EAN | 8013975080382 |
The Lovato 11BG0040A110 is a control relay designed for switching auxiliary circuits in industrial automation and electrical control systems.
The relay operates with a 110 V AC coil supply at 50/60 Hz.
This relay features four normally open contacts (4NO).
The relay can be installed using screw mounting or standard 35 mm DIN rail mounting.
It is commonly installed in industrial control panels, automation cabinets and electrical switching systems.
Lovato BG series control relays are widely used by engineers and panel builders to provide reliable switching, compact installation and dependable performance in industrial control applications.{ "@context": "https://schema.org/", "@type": "Product", "name": "Lovato 11BG0040A110 Control Relay 110V AC Coil 4 Pole 4NO", "sku": "11BG0040A110", "mpn": "11BG0040A110", "brand": { "@type": "Brand", "name": "Lovato" }, "category": "Industrial Control Relays", "description": "Lovato 11BG0040A110 control relay with 110V AC coil, four poles and four normally open contacts for industrial automation and electrical control systems.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Coil voltage", "value": "110 V AC" }, { "@type": "PropertyValue", "name": "Contact configuration", "value": "4NO" }, { "@type": "PropertyValue", "name": "Number of poles", "value": "4" }, { "@type": "PropertyValue", "name": "Rated current", "value": "10 A" }, { "@type": "PropertyValue", "name": "Mounting", "value": "DIN rail / screw mounting" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the Lovato 11BG0040A110 used for?", "acceptedAnswer": { "@type": "Answer", "text": "The Lovato 11BG0040A110 is a control relay designed for switching auxiliary circuits in industrial automation and electrical control systems." } }, { "@type": "Question", "name": "What coil voltage does this relay require?", "acceptedAnswer": { "@type": "Answer", "text": "The relay operates with a 110 V AC coil supply at 50/60 Hz." } }, { "@type": "Question", "name": "How many contacts does the Lovato 11BG0040A110 have?", "acceptedAnswer": { "@type": "Answer", "text": "This relay features four normally open contacts (4NO)." } }, { "@type": "Question", "name": "How is the Lovato 11BG0040A110 installed?", "acceptedAnswer": { "@type": "Answer", "text": "The relay can be installed using screw mounting or standard 35 mm DIN rail mounting." } }, { "@type": "Question", "name": "Where is this control relay commonly used?", "acceptedAnswer": { "@type": "Answer", "text": "It is commonly installed in industrial control panels, automation cabinets and electrical switching systems." } } ] }
