Lovato 11BG0040D125 industrial control relay with 125 V DC coil and 4NO auxiliary contacts, designed for industrial automation and machine control applications.
£47.45
The Lovato 11BG0040D125 is a compact and reliable industrial control relay with a DC coil designed for electrical automation systems, control panels and auxiliary switching applications. Part of the trusted Lovato BG00 series, this relay provides dependable switching performance for industrial machinery, motor control systems and automation installations.
Featuring a 125 V DC coil and a 4NO contact configuration, the Lovato 11BG0040D125 is designed for controlling auxiliary circuits where reliable operation, long service life and flexible installation are required. Its compact construction supports simple integration using 35 mm DIN rail or screw mounting.
With a 4-pole configuration, four normally open contacts and a robust industrial design, this Lovato control relay is suitable for PLC interfaces, machine automation, motor control panels and electrical cabinets requiring dependable auxiliary switching.
Industrial control relays such as the Lovato 11BG0040D125 provide dependable switching between PLC systems, controllers, contactors and auxiliary circuits. They allow automation engineers to create reliable control solutions while maintaining electrical separation between control and switched loads.
The Lovato BG00 series is developed for panel builders, machine manufacturers and automation professionals requiring compact components with dependable performance, simple installation and long operational durability.
| Voltage | 125 V |
|---|---|
| Phase | Three Phase |
| IP Rating | IP20 |
| Series | BG Series |
| Product type | Control relay |
| Number of poles | 4 |
| Auxiliary contact configuration | 4NO |
| Coil type | DC coil |
| Rated coil voltage | 125 V DC |
| Rated thermal current | 10 A AC1 |
| Maximum operating current | 6 A |
| Rated insulation voltage | 690 V |
| Rated impulse withstand voltage | 6 kV |
| Mounting type | Screw / DIN rail 35 mm |
| Terminal type | Screw terminals |
| Protection rating | IP20 |
| Mechanical endurance | 20 million cycles |
| Operating temperature | -50 °C to +70 °C |
| Dimensions (H × W × D) | approx. 60 × 45 × 60 mm |
| Weight | approx. 216 g |
| Standards | IEC/EN 60947-1, IEC/EN 60947-5-1, UL 60947-1, UL 60947-5-1, CSA C22.2 No. 60947-1, CSA C22.2 No. 60947-5-1 |
| EAN | 8013975082447 |
The Lovato 11BG0040D125 is a control relay designed for industrial automation, auxiliary switching and electrical control applications.
The relay operates using a 125 V DC coil supply.
This relay features four normally open contacts (4NO).
Yes, the relay supports 35 mm DIN rail mounting as well as screw mounting.
It is commonly installed in industrial control panels, automation cabinets and machine control systems.
Lovato BG00 series control relays are trusted by automation engineers and panel builders worldwide for reliable auxiliary switching, compact installation and durable industrial performance.{ "@context": "https://schema.org/", "@type": "Product", "name": "Lovato 11BG0040D125 Control Relay 125V DC Coil 4 Pole 4NO", "sku": "11BG0040D125", "mpn": "11BG0040D125", "brand": { "@type": "Brand", "name": "Lovato" }, "category": "Industrial Control Relays", "description": "Lovato 11BG0040D125 control relay with 125V DC coil, four poles and four normally open contacts for industrial automation and electrical control systems.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Coil voltage", "value": "125 V DC" }, { "@type": "PropertyValue", "name": "Contact configuration", "value": "4NO" }, { "@type": "PropertyValue", "name": "Number of poles", "value": "4" }, { "@type": "PropertyValue", "name": "Rated current", "value": "10 A" }, { "@type": "PropertyValue", "name": "Mounting", "value": "DIN rail / screw mounting" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the Lovato 11BG0040D125 used for?", "acceptedAnswer": { "@type": "Answer", "text": "The Lovato 11BG0040D125 is a control relay designed for industrial automation, auxiliary switching and electrical control applications." } }, { "@type": "Question", "name": "What coil voltage does this relay use?", "acceptedAnswer": { "@type": "Answer", "text": "The relay operates using a 125 V DC coil supply." } }, { "@type": "Question", "name": "What contact arrangement does the Lovato 11BG0040D125 provide?", "acceptedAnswer": { "@type": "Answer", "text": "This relay features four normally open contacts (4NO)." } }, { "@type": "Question", "name": "Can the Lovato 11BG0040D125 be mounted on a DIN rail?", "acceptedAnswer": { "@type": "Answer", "text": "Yes, the relay supports 35 mm DIN rail mounting as well as screw mounting." } }, { "@type": "Question", "name": "Where is this control relay commonly installed?", "acceptedAnswer": { "@type": "Answer", "text": "It is commonly installed in industrial control panels, automation cabinets and machine control systems." } } ] }
