Lovato 11BG0040L024 industrial control relay with low-consumption 24 V DC coil and 4NO auxiliary contacts, designed for industrial automation and machine control applications.
£47.45
The Lovato 11BG0040L024 is a compact and efficient industrial control relay with a low-consumption DC coil designed for automation systems, electrical control panels and auxiliary switching applications. Part of the reliable Lovato BG00 series, this relay provides dependable switching performance while reducing control circuit power consumption.
Featuring a 24 V DC low-consumption coil and a 4NO contact configuration, the Lovato 11BG0040L024 is designed for controlling auxiliary circuits where energy efficiency, reliable operation and long service life are required. Its compact construction allows simple installation using 35 mm DIN rail or screw mounting.
With a 4-pole configuration, 10 A thermal current rating and low-power DC coil technology, this Lovato control relay is suitable for PLC interfaces, industrial automation equipment, machine control panels and electrical cabinets requiring dependable auxiliary switching.
Industrial control relays such as the Lovato 11BG0040L024 provide dependable switching between PLC systems, controllers, contactors and auxiliary circuits. The low-consumption DC coil design helps improve control panel efficiency while maintaining reliable switching performance.
The Lovato BG00 series is developed for panel builders, machine manufacturers and automation professionals requiring compact components with dependable performance, simple installation and long operational durability.
| Voltage | 24 V |
|---|---|
| Phase | Three Phase |
| IP Rating | IP20 |
| Series | BG Series |
| Product type | Control relay |
| Number of poles | 4 |
| Auxiliary contact configuration | 4NO |
| Coil type | DC coil low consumption |
| Rated coil voltage | 24 V DC |
| Rated thermal current | 10 A AC1 |
| Maximum operating current | 6 A |
| Rated insulation voltage | 690 V |
| Rated impulse withstand voltage | 6 kV |
| Mounting type | Screw / DIN rail 35 mm |
| Terminal type | Screw terminals |
| Protection rating | IP20 |
| Mechanical endurance | 20 million cycles |
| Operating temperature | -50 °C to +70 °C |
| Dimensions (H × W × D) | approx. 58 × 44 × 60 mm |
| Weight | approx. 206 g |
| Standards | IEC/EN 60947-1, IEC/EN 60947-5-1, UL 60947-1, UL 60947-5-1, CSA C22.2 No. 60947-1, CSA C22.2 No. 60947-5-1 |
| EAN | 8013975081198 |
The Lovato 11BG0040L024 is a control relay designed for industrial automation, auxiliary switching and electrical control applications.
The relay operates using a 24 V DC low-consumption coil supply.
This relay features four normally open contacts (4NO).
Yes, the relay supports 35 mm DIN rail mounting as well as screw mounting.
The low-consumption DC coil reduces control power requirements while maintaining reliable relay operation.
Lovato BG00 series control relays are trusted by automation engineers and panel builders worldwide for reliable auxiliary switching, compact installation and energy-efficient industrial performance.{ "@context": "https://schema.org/", "@type": "Product", "name": "Lovato 11BG0040L024 Control Relay 24V DC Low Consumption Coil 4NO", "sku": "11BG0040L024", "mpn": "11BG0040L024", "brand": { "@type": "Brand", "name": "Lovato" }, "category": "Industrial Control Relays", "description": "Lovato 11BG0040L024 control relay with low-consumption 24V DC coil, four poles and four normally open contacts for industrial automation and electrical control systems.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Coil voltage", "value": "24 V DC" }, { "@type": "PropertyValue", "name": "Coil type", "value": "Low consumption DC coil" }, { "@type": "PropertyValue", "name": "Contact configuration", "value": "4NO" }, { "@type": "PropertyValue", "name": "Rated current", "value": "10 A" }, { "@type": "PropertyValue", "name": "Mounting", "value": "DIN rail / screw mounting" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the Lovato 11BG0040L024 used for?", "acceptedAnswer": { "@type": "Answer", "text": "The Lovato 11BG0040L024 is a control relay designed for industrial automation, auxiliary switching and electrical control applications." } }, { "@type": "Question", "name": "What coil voltage does this relay use?", "acceptedAnswer": { "@type": "Answer", "text": "The relay operates using a 24 V DC low-consumption coil supply." } }, { "@type": "Question", "name": "What contact arrangement does the Lovato 11BG0040L024 provide?", "acceptedAnswer": { "@type": "Answer", "text": "This relay features four normally open contacts (4NO)." } }, { "@type": "Question", "name": "Can the Lovato 11BG0040L024 be mounted on a DIN rail?", "acceptedAnswer": { "@type": "Answer", "text": "Yes, the relay supports 35 mm DIN rail mounting as well as screw mounting." } }, { "@type": "Question", "name": "What makes the low-consumption coil version different?", "acceptedAnswer": { "@type": "Answer", "text": "The low-consumption DC coil reduces control power requirements while maintaining reliable relay operation." } } ] }
