Lovato 11BG0901A02460 three-pole mini contactor with 24 V AC/DC universal coil, 9 A AC3 operational current and integrated 1 NC auxiliary contact for industrial automation and motor control systems.
£43.85
The Lovato 11BG0901A02460 is a compact and reliable three-pole industrial contactor designed for switching and controlling motors and electrical loads in industrial automation, machinery and control panel applications. Part of the Lovato BG series contactors, it features a 24V AC coil (60Hz) and an integrated 1NC auxiliary contact with mirror contact function for dependable control and monitoring.
This contactor is engineered for OEM machine builders, electrical panel manufacturers and automation professionals requiring a compact switching solution with reliable electrical performance. Its space-saving construction, screw terminals and compatibility with 35mm DIN rail mounting simplify installation in industrial control cabinets.
With an IEC AC-3 rated operating current of 9A, an AC-1 thermal current rating of 20A and support for motors up to approximately 4 kW at 400V AC, the Lovato 11BG0901A02460 is suitable for controlling three-phase motors and industrial equipment. The integrated 1NC auxiliary contact provides additional monitoring and control capability.
Industrial contactors such as the Lovato 11BG0901A02460 provide dependable electrical switching by allowing low-power control signals to operate higher-power motor circuits. This improves automation efficiency while supporting safer and more organised electrical system designs.
The BG series contactors are developed for applications requiring compact dimensions, reliable switching performance and simple installation. The auxiliary contact arrangement enables integration with PLC systems, machine controllers and industrial monitoring solutions.
| Power | 4 kW |
|---|---|
| Current | 9 A |
| Voltage | 24 V |
| Phase | Three Phase |
| Series | BG Mini Contactors |
| Product type | Three-pole mini contactor |
| Number of poles | 3 |
| Auxiliary contacts | 1 NC |
| Operational current AC3 | 9 A |
| Motor power at 400 V AC | 4 kW |
| Rated insulation voltage | 690 V |
| Control coil voltage | 24 V AC/DC |
| Frequency | 50/60 Hz |
| Mounting type | DIN rail 35 mm / screw mounting |
| Terminal type | Screw terminals |
| Width | approx. 45 mm |
| Height | approx. 58 mm |
| Depth | approx. 57 mm |
| Protection degree | IP20 |
| Operating temperature | approx. -40 °C to +60 °C |
| Standards | IEC/EN 60947-1, IEC/EN 60947-4-1 |
| Weight | approx. 230 g |
The Lovato 11BG0901A02460 is a three-pole contactor designed for switching and controlling motors and electrical loads in industrial automation applications.
This contactor operates with a 24V AC coil at 60Hz suitable for industrial control systems.
The contactor has an AC-3 rated operating current of 9A and supports motor loads up to approximately 4 kW at 400V AC.
Yes, the Lovato 11BG0901A02460 includes a 1NC auxiliary contact with mirror contact functionality for monitoring and control.
The contactor can be installed using screw fixing or mounted on a standard 35mm DIN rail.
Lovato BG series contactors are widely used in industrial control systems to provide dependable motor switching, compact installation and reliable automation performance.{ "@context": "https://schema.org/", "@type": "Product", "name": "Lovato 11BG0901A02460 Three Pole Contactor 24V AC Coil", "sku": "11BG0901A02460", "mpn": "11BG0901A02460", "brand": { "@type": "Brand", "name": "Lovato" }, "category": "Industrial Contactors", "description": "Lovato 11BG0901A02460 three-pole contactor with 24V AC 60Hz coil, 9A AC-3 rating and 1NC auxiliary contact for industrial motor control and automation applications.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Coil voltage", "value": "24V AC" }, { "@type": "PropertyValue", "name": "Operating current", "value": "9A AC-3" }, { "@type": "PropertyValue", "name": "Number of poles", "value": "3" }, { "@type": "PropertyValue", "name": "Auxiliary contact", "value": "1NC" }, { "@type": "PropertyValue", "name": "Mounting", "value": "DIN rail / screw mounting" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the Lovato 11BG0901A02460 used for?", "acceptedAnswer": { "@type": "Answer", "text": "The Lovato 11BG0901A02460 is a three-pole contactor designed for switching and controlling motors and electrical loads in industrial automation applications." } }, { "@type": "Question", "name": "What coil voltage does this contactor require?", "acceptedAnswer": { "@type": "Answer", "text": "This contactor operates with a 24V AC coil at 60Hz suitable for industrial control systems." } }, { "@type": "Question", "name": "What is the rated current of the Lovato 11BG0901A02460?", "acceptedAnswer": { "@type": "Answer", "text": "The contactor has an AC-3 rated operating current of 9A and supports motor loads up to approximately 4 kW at 400V AC." } }, { "@type": "Question", "name": "Does this contactor include auxiliary contacts?", "acceptedAnswer": { "@type": "Answer", "text": "Yes, the Lovato 11BG0901A02460 includes a 1NC auxiliary contact with mirror contact functionality for monitoring and control." } }, { "@type": "Question", "name": "How is the Lovato 11BG0901A02460 mounted?", "acceptedAnswer": { "@type": "Answer", "text": "The contactor can be installed using screw fixing or mounted on a standard 35mm DIN rail." } } ] }
