11BG09T2A024 – 4P MINICONTACTOR BG09.T2A 24V 50-60HZ

Q: What coil voltage does this contactor require?

The contactor operates with a 24V AC 50/60Hz coil supply.

Q: What is the contact configuration of the Lovato 11BG09T2A024?

The contactor includes a 2NO + 2NC contact configuration for flexible switching and control functions.

Lovato 11BG09T2A024 four-pole mini contactor with 24 V AC 50/60 Hz coil, 2NO + 2NC contact configuration and 9 A AC3 operational current for industrial automation and switching systems.

SKU: 11BG09T2A024Alt SKU: BG09T2A024MPN: 11BG09T2A024

List Price £55.04 ex VAT

Your Price (ex VAT)

£55.04

Manufacturer Lead Time Please contact us for a delivery time before you order

Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Quantity:

SUBTOTAL (EX VAT) £55.04

Trade pricing is personalised to your account

Manufacturer Lead Time

£55.04

Why Choose the Lovato 11BG09T2A024 Four-Pole Contactor?

The Lovato 11BG09T2A024 is a compact and reliable four-pole contactor designed for switching and controlling electrical loads in industrial automation and control systems. Part of the Lovato BG contactor series, this device provides dependable switching performance for motor control panels, HVAC systems and industrial machinery applications.

Featuring a 24V AC 50/60Hz coil, 9A IEC AC-3 operating current and a 2NO + 2NC contact configuration, the 11BG09T2A024 offers flexible control and auxiliary switching capability. Its compact construction enables efficient installation in space-limited electrical cabinets while maintaining reliable operation in demanding industrial environments.

The Lovato 11BG09T2A024 is suitable for applications requiring multiple switching contacts, including automation equipment, control circuits, power distribution systems and OEM machinery. With screw terminals and compatibility with 35mm DIN rail mounting, installation is straightforward for panel builders and maintenance engineers.

Key Advantages

Compact four-pole contactor for industrial switching applications.
9A AC-3 rated operating current for motor and load control systems.
24V AC coil voltage suitable for industrial control circuits.
2NO + 2NC contact arrangement for flexible switching functions.
DIN rail and screw mounting compatibility for easy installation.
Reliable switching performance for automation and control applications.

Key Features

Lovato BG series mini contactor.
Four main switching poles.
2 normally open and 2 normally closed contacts.
9A IEC AC-3 rated current at 400V.
4.0kW motor switching capability at 400V AC-3.
24V AC 50/60Hz operating coil.
Screw terminal connections.
35mm DIN rail mounting capability.

Reliable Switching for Industrial Automation

Contactors such as the Lovato 11BG09T2A024 provide safe and efficient electrical switching for industrial equipment and control systems. They allow automation systems to manage electrical loads using reliable electromagnetic switching technology.

The Lovato BG series is designed for applications where compact size, flexible contact arrangements and dependable switching performance are essential. The four-pole configuration allows integration into a wide range of industrial control and automation circuits.

Typical Applications

Industrial control panels and automation systems.
Motor control and switching applications.
HVAC and ventilation equipment.
OEM machinery and electrical assemblies.
Control circuit switching applications.
Industrial electrical distribution systems.

Technical Specifications

Coil Voltage Range	24 V
Power	4 kW
Current	9 A
Voltage	24 V
Phase	Three Phase
Series	BG Mini Contactors
Product type	Four-pole mini contactor
Number of poles	4
Contact configuration	2NO + 2NC
Operational current AC3	9 A
Thermal current AC1	20 A
Motor power at 400 V AC	4 kW
UL/CSA horsepower rating at 480 V	5 HP
Rated insulation voltage	690 V
Control coil voltage	24 V AC 50/60 Hz
Mounting type	DIN rail 35 mm / screw mounting
Terminal type	Screw terminals
Width	44 mm
Height	58 mm
Depth	60 mm
Weight	approx. 179 g
Protection degree	IP20
Operating temperature	-40 °C to +60 °C
Mechanical life	up to 20 million operations
Electrical life	up to 500,000 operations
Standards	IEC/EN 60947-1, IEC/EN 60947-4-1, UL 60947-1, UL 60947-4-1
EAN	8013975082140
Poles	4-pole
Device Type	Mini contactor
Coil Type	AC
Current AC-1	20 A

Frequently Asked Questions

What is the Lovato 11BG09T2A024 used for?

The Lovato 11BG09T2A024 is a four-pole contactor used for switching and controlling electrical loads in industrial automation and control systems.

What coil voltage does this contactor require?

The contactor operates with a 24V AC 50/60Hz coil supply.

What is the contact configuration of the Lovato 11BG09T2A024?

The contactor includes a 2NO + 2NC contact configuration for flexible switching and control functions.

What is the rated current of this contactor?

The contactor has an IEC AC-3 operating current rating of 9A at 400V.

How is the Lovato 11BG09T2A024 mounted?

The contactor can be mounted using screw terminals or installed on a standard 35mm DIN rail.

Trusted by Industrial Automation Professionals

Lovato BG series contactors are widely used in industrial control systems to provide dependable switching, flexible control integration and reliable electrical performance.

Coil Voltage Range	24 V
Power	4 kW
Current	9 A
Voltage	24 V
Phase	Three Phase
Series	BG Mini Contactors
Product type	Four-pole mini contactor
Number of poles	4
Contact configuration	2NO + 2NC
Operational current AC3	9 A
Thermal current AC1	20 A
Motor power at 400 V AC	4 kW
UL/CSA horsepower rating at 480 V	5 HP
Rated insulation voltage	690 V
Control coil voltage	24 V AC 50/60 Hz
Mounting type	DIN rail 35 mm / screw mounting
Terminal type	Screw terminals
Width	44 mm
Height	58 mm
Depth	60 mm
Weight	approx. 179 g
Protection degree	IP20
Operating temperature	-40 °C to +60 °C
Mechanical life	up to 20 million operations
Electrical life	up to 500,000 operations
Standards	IEC/EN 60947-1, IEC/EN 60947-4-1, UL 60947-1, UL 60947-4-1
EAN	8013975082140
Poles	4-pole
Device Type	Mini contactor
Coil Type	AC
Current AC-1	20 A
