11BGF0022A024 - CONTROL RELAY BGF00.22A 24V 50/60 FASTON

11BGF0022A024 – CONTROL RELAY BGF00.22A 24V 50/60 FASTON

Lovato 11BGF0022A024 four-pole control relay with 24 V AC 50/60Hz coil, 2NO plus 2NC contacts and Faston terminals for industrial automation and auxiliary switching applications.

SKU: 11BGF0022A024Alt SKU: BGF0022A024MPN: 11BGF0022A024
Price
List Price £54.12 ex VAT
Your Price (ex VAT)
£54.12
Manufacturer Lead Time Please contact us for a delivery time before you order
Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Sign up for a trade account Quick & easy setup
SUBTOTAL (EX VAT) £54.12
Trade pricing is personalised to your account

Manufacturer Lead Time

£54.12

Why Choose the Lovato 11BGF0022A024 Control Relay?

The Lovato 11BGF0022A024 is a compact and reliable control relay designed for industrial automation, electrical control panels and switching applications. As part of the Lovato BG series, this device provides dependable auxiliary switching functionality for control circuits, machinery and industrial installations.

Featuring a 24 V AC coil, four-pole configuration and 2 normally open (NO) plus 2 normally closed (NC) contacts, the 11BGF0022A024 provides flexible signal control and circuit management for automation systems. Its compact design allows easy installation using Faston terminals with screw or 35 mm DIN rail mounting compatibility.

With a control relay contact rating suitable for industrial switching applications and compliance with international standards including IEC/EN 60947-5-1, the Lovato 11BGF0022A024 is ideal for reliable control functions in electrical systems where compact dimensions and high switching endurance are required.

Key Advantages

  • Compact Lovato BG series control relay for industrial automation.
  • 24 V AC coil voltage suitable for control circuits.
  • 4-pole contact configuration with flexible NO and NC switching.
  • 2NO + 2NC auxiliary contacts for control and monitoring functions.
  • Faston terminal connections for efficient wiring.
  • DIN rail and screw mounting compatibility for panel installation.

Key Features

  • Lovato Electric BG series control relay.
  • Four-pole configuration.
  • 2 normally open contacts (NO).
  • 2 normally closed contacts (NC).
  • 24 V AC coil operating voltage.
  • AC coil frequency 50/60 Hz.
  • Faston terminal connection type.
  • High mechanical endurance for industrial applications.
  • 35 mm DIN rail mounting capability.

Reliable Control Switching for Industrial Automation

The Lovato 11BGF0022A024 control relay provides dependable switching of auxiliary control circuits in industrial automation systems. Control relays are essential components for managing signals, interlocks and control logic within electrical panels.

Designed for machine builders and automation engineers, the BG series offers compact dimensions, high switching reliability and simple integration into modern control systems. Its versatile contact arrangement allows use in a wide range of industrial applications.

Typical Applications

  • Industrial automation control panels.
  • Machine control and electrical cabinets.
  • Motor control circuits.
  • PLC interface and signalling systems.
  • Industrial switching and control applications.
  • OEM machinery and automation equipment.

Technical Specifications

Coil Voltage Range 24 V
Current 10 A
Voltage 24 V
Phase Three Phase
IP Rating IP20
Series BGF Control Relays
Product type Control relay
Number of poles 4
Contact configuration 2NO + 2NC
Rated operational current 10 A AC1
Control coil type AC coil 50/60Hz
Control coil voltage 24 V AC
Rated insulation voltage 690 V
Mounting type DIN rail 35 mm / screw mounting
Terminal type Faston terminals
Protection rating IP20 when correctly installed
Operating temperature approx. -40 to +60 °C
Dimensions (H × W × D) approx. 58 × 44 × 57 mm
Weight approx. 178 g
EAN 8013975120224
Poles 4-pole
Contacts 2NO + 2NC
Device Type Contactor relay
Coil Type AC

Frequently Asked Questions

What is the Lovato 11BGF0022A024 used for?

The Lovato 11BGF0022A024 is a control relay used for switching auxiliary control circuits in industrial automation and electrical control systems.

What coil voltage does this relay require?

This control relay uses a 24 V AC coil operating at 50/60 Hz.

How many contacts does the Lovato 11BGF0022A024 have?

The relay features four contacts configured as 2 normally open and 2 normally closed.

Can this relay be mounted on a DIN rail?

Yes, the Lovato 11BGF0022A024 supports 35 mm DIN rail mounting as well as screw installation.

What type of terminals are used?

This model uses Faston terminal connections for electrical wiring.

Trusted for Industrial Control Applications

Lovato Electric BG series control relays are widely used by automation engineers and industrial manufacturers for reliable switching, flexible control solutions and long-lasting performance in electrical systems.
