11BGF0022A230 – CONTROL RELAY BGF00.22A 230V 50/60FASTON

Q: What coil voltage does this relay require?

This relay uses a 230V AC coil operating at 50/60Hz.

Q: How many contacts does the relay have?

The relay features a 4-pole configuration with 2 normally open and 2 normally closed contacts.

Lovato 11BGF0022A230 four-pole control relay with 230 V AC 50/60Hz coil, 2NO plus 2NC contacts and Faston terminals for industrial automation and auxiliary switching applications.

SKU: 11BGF0022A230Alt SKU: BGF0022A230MPN: 11BGF0022A230

List Price £54.12 ex VAT

Your Price (ex VAT)

£54.12

Manufacturer Lead Time Please contact us for a delivery time before you order

Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Quantity:

SUBTOTAL (EX VAT) £54.12

Trade pricing is personalised to your account

Manufacturer Lead Time

£54.12

Why Choose the Lovato 11BGF0022A230 Control Relay?

The Lovato 11BGF0022A230 is a compact and dependable industrial control relay designed for electrical automation, machine control and switching applications. Part of the Lovato Electric BGF series, this relay provides reliable auxiliary circuit control with a 230V AC 50/60Hz coil and a flexible 4-pole contact arrangement.

Designed for automation engineers, panel builders and OEM manufacturers, the 11BGF0022A230 delivers efficient switching performance in compact control systems. Its robust construction, Faston terminals and DIN rail mounting capability make it suitable for professional industrial installations where reliable operation is required.

Featuring a 2NO + 2NC auxiliary contact configuration and a 230V AC coil supply, this Lovato control relay is ideal for motor control panels, automation equipment and electrical distribution systems. The compact BGF design allows straightforward integration into modern industrial control cabinets.

Key Advantages

Compact control relay designed for industrial automation.
230V AC coil voltage suitable for standard industrial control circuits.
2NO + 2NC auxiliary contacts for flexible switching functions.
Faston terminal connection for quick installation.
Compatible with 35mm DIN rail mounting.
Reliable Lovato Electric solution for control and switching applications.

Key Features

Lovato Electric BGF series control relay.
4-pole contact configuration.
2 normally open and 2 normally closed contacts.
230V AC coil supply at 50/60Hz.
Faston terminal connections.
DIN rail 35mm or screw mounting installation.
Compact design for electrical control panels.
Suitable for industrial automation and machine control systems.

Reliable Switching for Industrial Control Systems

The Lovato 11BGF0022A230 provides dependable switching of auxiliary circuits in industrial automation equipment. Control relays allow engineers to separate control signals from power circuits while improving system organisation, safety and operational reliability.

The Lovato BGF series combines compact dimensions with reliable electrical performance, making it a practical choice for machine builders and industrial electricians requiring efficient control solutions in panel applications.

Typical Applications

Industrial automation control panels.
Motor starter and control circuits.
OEM machinery and machine building.
Electrical distribution systems.
PLC interface and auxiliary switching applications.
Factory automation equipment.

Technical Specifications

Coil Voltage Range	200–250 V
Current	10 A
Voltage	230 V
Phase	Three Phase
IP Rating	IP20
Series	BGF Control Relays
Product type	Control relay
Number of poles	4
Contact configuration	2NO + 2NC
Rated operational current	10 A AC1
Control coil type	AC coil 50/60Hz
Control coil voltage	230 V AC
Rated insulation voltage	690 V
Mounting type	DIN rail 35 mm / screw mounting
Terminal type	Faston terminals
Protection rating	IP20 when correctly installed
Standards	IEC/EN 60947-1, IEC/EN 60947-5-1, UL 60947-1
Operating temperature	approx. -50 to +70 °C
Dimensions (H × W × D)	approx. 58 × 44 × 57 mm
Weight	approx. 182 g
EAN	8013975120316
Poles	4-pole
Contacts	2NO + 2NC
Device Type	Contactor relay
Coil Type	AC

Frequently Asked Questions

What is the Lovato 11BGF0022A230 used for?

The Lovato 11BGF0022A230 is a control relay used for switching auxiliary circuits in industrial automation and electrical control systems.

What coil voltage does this relay require?

This relay uses a 230V AC coil operating at 50/60Hz.

How many contacts does the relay have?

The relay features a 4-pole configuration with 2 normally open and 2 normally closed contacts.

How is the Lovato 11BGF0022A230 installed?

The relay can be installed using screw mounting or on a standard 35mm DIN rail.

Where is this control relay typically used?

It is commonly installed in industrial control panels, automation cabinets and machine control systems.

Trusted for Industrial Automation Applications

Lovato Electric control relays are widely used by automation professionals and electrical engineers to provide reliable switching, compact installation and dependable performance in industrial systems.
