11BGF0022L024 – CONTROL RELAY FASTON LOW CONSUMPTION COI

Q: What coil voltage does this relay require?

This relay uses a 24V DC low-consumption coil designed for efficient industrial control applications.

Q: How many contacts does the relay have?

The relay features a 4-pole configuration with 2 normally open and 2 normally closed contacts.

Lovato 11BGF0022L024 four-pole low consumption control relay with 24 V DC coil, 2NO plus 2NC contacts and Faston terminals for industrial automation and auxiliary switching applications.

SKU: 11BGF0022L024Alt SKU: BGF0022L024MPN: 11BGF0022L024

List Price £75.86 ex VAT

Your Price (ex VAT)

£75.86

Manufacturer Lead Time Please contact us for a delivery time before you order

Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Quantity:

SUBTOTAL (EX VAT) £75.86

Trade pricing is personalised to your account

Manufacturer Lead Time

£75.86

Why Choose the Lovato 11BGF0022L024 Control Relay?

The Lovato 11BGF0022L024 is a compact and efficient industrial control relay designed for automation systems, electrical control panels and auxiliary switching applications. Part of the Lovato Electric BGF series, this relay features a low consumption 24V DC coil and provides reliable switching with a flexible 4-pole contact configuration.

Designed for machine builders, panel manufacturers and automation engineers, the 11BGF0022L024 combines dependable electrical performance with reduced coil power consumption. Its Faston terminal connection and DIN rail mounting capability make it suitable for compact industrial control installations.

Featuring a 2NO + 2NC auxiliary contact arrangement, 24V DC low-consumption coil and a 4-pole design, this Lovato control relay is ideal for PLC interface circuits, industrial machinery, motor control panels and automation equipment requiring reliable auxiliary switching.

Key Advantages

Compact industrial control relay for automation applications.
Low consumption 24V DC coil for energy-efficient control circuits.
2NO + 2NC auxiliary contacts for flexible switching functions.
Faston terminal connection for quick and reliable installation.
Suitable for 35mm DIN rail and screw mounting.
Reliable Lovato Electric construction for industrial environments.

Key Features

Lovato Electric BGF series control relay.
Low consumption DC coil technology.
24V DC rated coil voltage.
4-pole contact configuration.
2 normally open + 2 normally closed contacts.
Faston terminal connections.
DIN rail 35mm mounting capability.
Compact design for industrial control cabinets.

Reliable Switching for Industrial Control Systems

The Lovato 11BGF0022L024 provides dependable control of auxiliary electrical circuits while reducing energy consumption through its low-consumption DC coil design. This makes it an efficient solution for modern automation systems where reliability and power efficiency are important.

The Lovato BGF series is engineered for professional industrial applications requiring compact dimensions, reliable switching performance and simple installation. Its versatile contact configuration supports a wide range of control and automation requirements.

Typical Applications

Industrial automation control panels.
PLC interface and control circuits.
Motor starter and auxiliary switching systems.
OEM machinery and machine building applications.
Electrical distribution control systems.
Factory automation equipment.

Technical Specifications

Coil Voltage Range	24 V
Current	10 A
Voltage	24 V
Phase	Three Phase
IP Rating	IP20
Series	BGF Control Relays
Product type	Low consumption control relay
Number of poles	4
Contact configuration	2NO + 2NC
Rated operational current	10 A AC1
Maximum operating current	3 A
Control coil type	DC coil low consumption
Control coil voltage	24 V DC
Rated insulation voltage	690 V
Rated impulse withstand voltage	6 kV
Mounting type	Screw mounting / DIN rail 35 mm
Terminal type	Faston terminals
Protection rating	IP20 when wired
Mechanical life	20 million operating cycles
Operating temperature	approx. -50 to +70 °C
Dimensions (H × W × D)	approx. 58 × 44 × 57 mm
Weight	approx. 220 g
EAN	8013975120446
Poles	4-pole
Contacts	2NO + 2NC
Device Type	Contactor relay
Coil Type	DC

Frequently Asked Questions

What is the Lovato 11BGF0022L024 used for?

The Lovato 11BGF0022L024 is a control relay used for switching auxiliary circuits in industrial automation and electrical control systems.

What coil voltage does this relay require?

This relay uses a 24V DC low-consumption coil designed for efficient industrial control applications.

How many contacts does the relay have?

The relay features a 4-pole configuration with 2 normally open and 2 normally closed contacts.

How is the Lovato 11BGF0022L024 installed?

The relay can be installed using screw mounting or on a standard 35mm DIN rail.

Where is this control relay typically used?

It is commonly installed inside industrial control panels, automation cabinets and machine control systems.

Trusted for Industrial Automation Applications

Lovato Electric control relays are widely used by automation professionals and electrical engineers to provide reliable switching, compact installation and efficient performance in industrial systems.

Coil Voltage Range	24 V
Current	10 A
Voltage	24 V
Phase	Three Phase
IP Rating	IP20
Series	BGF Control Relays
Product type	Low consumption control relay
Number of poles	4
Contact configuration	2NO + 2NC
Rated operational current	10 A AC1
Maximum operating current	3 A
Control coil type	DC coil low consumption
Control coil voltage	24 V DC
Rated insulation voltage	690 V
Rated impulse withstand voltage	6 kV
Mounting type	Screw mounting / DIN rail 35 mm
Terminal type	Faston terminals
Protection rating	IP20 when wired
Mechanical life	20 million operating cycles
Operating temperature	approx. -50 to +70 °C
Dimensions (H × W × D)	approx. 58 × 44 × 57 mm
Weight	approx. 220 g
EAN	8013975120446
Poles	4-pole
Contacts	2NO + 2NC
Device Type	Contactor relay
Coil Type	DC
