Lovato 11BGF0031A048 four-pole control relay with 48 V AC 50/60Hz coil, 3NO plus 1NC contacts and Faston terminals for industrial automation and auxiliary switching applications.
£54.12
The Lovato 11BGF0031A048 is a compact and reliable industrial control relay designed for electrical automation, machine control and auxiliary switching applications. Part of the Lovato Electric BGF series, this relay provides dependable switching performance with a 48V AC 50/60Hz coil and a flexible 4-pole contact arrangement featuring 3 normally open and 1 normally closed contacts.
Designed for automation engineers, panel builders and OEM manufacturers, the 11BGF0031A048 combines robust electrical performance with a compact design suitable for modern control cabinets. Its Faston terminal connection and DIN rail mounting capability allow straightforward installation and reliable operation in industrial automation systems.
Featuring a 3NO + 1NC auxiliary contact configuration and a 48V AC coil supply, this Lovato control relay is ideal for motor control panels, PLC interface circuits, machinery and industrial electrical systems requiring dependable auxiliary switching.
The Lovato 11BGF0031A048 provides dependable switching of auxiliary circuits in industrial automation equipment. Control relays allow engineers to manage electrical control functions efficiently while improving system reliability and simplifying panel layouts.
The Lovato BGF series is designed for professional automation applications where compact dimensions, reliable operation and straightforward installation are essential. Its versatile 3NO + 1NC contact configuration makes it suitable for a broad range of industrial control solutions.
| Current | 10 A |
|---|---|
| Voltage | 48 V |
| Phase | Three Phase |
| IP Rating | IP20 |
| Series | BGF Control Relays |
| Product type | Control relay |
| Number of poles | 4 |
| Contact configuration | 3NO + 1NC |
| Rated operational current | 10 A AC1 |
| Control coil type | AC coil 50/60Hz |
| Control coil voltage | 48 V AC |
| Rated insulation voltage | 690 V |
| Mounting type | Screw mounting / DIN rail 35 mm |
| Terminal type | Faston terminals |
| Protection rating | IP20 when correctly installed |
| Standards | IEC/EN 60947-1, IEC/EN 60947-5-1, UL 60947-1, UL 60947-5-1 |
| Operating temperature | approx. -50 to +70 °C |
| Dimensions (H × W × D) | approx. 58 × 44 × 57 mm |
| Weight | approx. 180 g |
| EAN | 8013975120484 |
The Lovato 11BGF0031A048 is a control relay used for switching auxiliary circuits in industrial automation and electrical control systems.
This relay uses a 48V AC coil operating at 50/60Hz.
The relay features a 4-pole configuration with 3 normally open and 1 normally closed contacts.
The relay can be installed using screw mounting or on a standard 35mm DIN rail.
It is commonly installed inside industrial control panels, automation cabinets and machine control systems.
Lovato Electric control relays are widely used by automation professionals and electrical engineers to provide reliable switching, compact installation and dependable performance in industrial systems.{ "@context": "https://schema.org/", "@type": "Product", "name": "Lovato 11BGF0031A048 Control Relay 48V AC 3NO 1NC", "sku": "11BGF0031A048", "mpn": "11BGF0031A048", "brand": { "@type": "Brand", "name": "Lovato Electric" }, "category": "Control Relays", "description": "Lovato 11BGF0031A048 control relay with 48V AC coil, 4 poles and 3NO+1NC auxiliary contacts for industrial automation and control applications.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Coil voltage", "value": "48 V AC" }, { "@type": "PropertyValue", "name": "Contact configuration", "value": "3NO + 1NC" }, { "@type": "PropertyValue", "name": "Number of poles", "value": "4" }, { "@type": "PropertyValue", "name": "Mounting", "value": "DIN rail 35mm / screw mounting" }, { "@type": "PropertyValue", "name": "Terminal type", "value": "Faston terminals" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the Lovato 11BGF0031A048 used for?", "acceptedAnswer": { "@type": "Answer", "text": "The Lovato 11BGF0031A048 is a control relay used for switching auxiliary circuits in industrial automation and electrical control systems." } }, { "@type": "Question", "name": "What coil voltage does this relay require?", "acceptedAnswer": { "@type": "Answer", "text": "This relay uses a 48V AC coil operating at 50/60Hz." } }, { "@type": "Question", "name": "How many contacts does the relay have?", "acceptedAnswer": { "@type": "Answer", "text": "The relay features a 4-pole configuration with 3 normally open and 1 normally closed contacts." } }, { "@type": "Question", "name": "How is the Lovato 11BGF0031A048 installed?", "acceptedAnswer": { "@type": "Answer", "text": "The relay can be installed using screw mounting or on a standard 35mm DIN rail." } }, { "@type": "Question", "name": "Where is this control relay typically used?", "acceptedAnswer": { "@type": "Answer", "text": "It is commonly installed inside industrial control panels, automation cabinets and machine control systems." } } ] }
