11BGF0901L048 – MINICONTACTOR 3P+1NC 9A DC/COIL FASTON

Q: What coil voltage does this contactor require?

The contactor uses a 48V DC low-consumption coil for efficient industrial control circuit operation.

Q: What is the rated current of the Lovato 11BGF0901L048?

The contactor has an IEC AC-3 operating current rating of 9A at 400V.

Q: Does this contactor include auxiliary contacts?

Yes, the unit includes a built-in 1NC auxiliary contact for additional control and monitoring functions.

Q: How is the contactor installed?

The Lovato 11BGF0901L048 can be installed using 35mm DIN rail mounting or screw fixing inside electrical control panels.

Lovato 11BGF0901L048 three-pole industrial mini contactor with 48 V DC low-consumption coil, 9 A AC3 operational current, 1NC auxiliary contact and Faston terminals for industrial motor control applications.

SKU: 11BGF0901L048Alt SKU: BGF0901L048MPN: 11BGF0901L048

List Price £79.21 ex VAT

Your Price (ex VAT)

£79.21

Manufacturer Lead Time Please contact us for a delivery time before you order

Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Quantity:

SUBTOTAL (EX VAT) £79.21

Trade pricing is personalised to your account

Manufacturer Lead Time

£79.21

Why Choose the Lovato 11BGF0901L048 Three-Pole Contactor?

The Lovato 11BGF0901L048 is a compact and efficient three-pole industrial contactor designed for reliable switching of motors and electrical loads in automation and control systems. Part of the Lovato BG series contactors, this device provides dependable operation for industrial machinery, motor starters and electrical control panels.

Featuring a low-consumption 48V DC coil, 9A AC-3 operating current rating and an integrated 1NC auxiliary contact, the 11BGF0901L048 delivers efficient control performance while reducing energy consumption in DC control circuits.

The Lovato 11BGF0901L048 includes three main power poles, Faston terminal connections and DIN rail mounting compatibility, allowing straightforward installation in electrical cabinets, motor starters and industrial automation systems.

Key Advantages

Compact three-pole contactor for industrial motor control applications.
48V DC low-consumption coil for efficient control circuit operation.
9A AC-3 rated operating current for motor switching duties.
Integrated 1NC auxiliary contact for additional control functions.
Faston terminals provide secure and efficient wiring connections.
DIN rail and screw mounting options simplify installation.

Key Features

Lovato BG series industrial contactor.
Three main power poles.
48V DC low-consumption coil.
9A IEC AC-3 operating current at 400V.
20A IEC AC-1 thermal current rating.
Built-in 1NC auxiliary contact.
Faston terminal connections.
DIN rail 35mm and screw mounting capability.
Suitable for motor starters and industrial automation systems.

Reliable Switching for Industrial Control Systems

Industrial contactors such as the Lovato 11BGF0901L048 allow low-power control circuits to safely operate higher-power electrical loads. They are essential components in industrial automation, machine control systems and motor starter assemblies where reliable switching performance is required.

The Lovato BG series combines compact dimensions with dependable electrical performance, helping engineers create efficient control panels with reduced installation space. The low-consumption DC coil improves energy efficiency while maintaining reliable contactor operation.

Typical Applications

Three-phase motor starters.
Industrial automation control panels.
Machine building and OEM equipment.
Pumps and ventilation systems.
Material handling machinery.
Manufacturing and process control equipment.

Technical Specifications

Coil Voltage Range	42–48 V
Power	4 kW
Current	9 A
Voltage	48 V
Phase	Three Phase
IP Rating	IP20
Series	BG Series
Product type	Three-pole mini contactor
Number of poles	3
Coil type	DC coil low consumption
Rated coil voltage	48 V DC
IEC operational current AC3	9 A
Motor power at 400 V AC3	4 kW
Thermal current AC1	20 A
Auxiliary contacts	1NC
Terminal type	Faston terminals
Mounting type	Screw mounting / DIN rail 35 mm
Rated insulation voltage	690 V
Horsepower rating at 480 V	5 HP
Protection rating	IP20 when installed
Mechanical life	approx. 20 million operations
Electrical life	approx. 500,000 operations
Operating temperature	approx. -40 °C to +60 °C
Dimensions	approx. 58 × 44 × 57 mm
Weight	approx. 224 g
EAN	8013975121184
Standards	IEC/EN 60947-1, IEC/EN 60947-4-1, UL 60947-1, UL 60947-4-1
Poles	3-pole
Coil / Supply Voltage	48 V DC
Device Type	Mini contactor
Auxiliary Contacts	1NC
Coil Type	DC
Current AC-1	20 A

Frequently Asked Questions

What is the Lovato 11BGF0901L048 used for?

The Lovato 11BGF0901L048 is a three-pole contactor used for switching and controlling motors and industrial electrical loads.

What coil voltage does this contactor require?

The contactor uses a 48V DC low-consumption coil for efficient industrial control circuit operation.

What is the rated current of the Lovato 11BGF0901L048?

The contactor has an IEC AC-3 operating current rating of 9A at 400V.

Does this contactor include auxiliary contacts?

Yes, the unit includes a built-in 1NC auxiliary contact for additional control and monitoring functions.

How is the contactor installed?

The Lovato 11BGF0901L048 can be installed using 35mm DIN rail mounting or screw fixing inside electrical control panels.

Trusted for Industrial Motor Control

Lovato BG series contactors are widely used by automation engineers and panel builders to provide reliable switching, compact installation and long-lasting performance in industrial control systems.

Coil Voltage Range	42–48 V
Power	4 kW
Current	9 A
Voltage	48 V
Phase	Three Phase
IP Rating	IP20
Series	BG Series
Product type	Three-pole mini contactor
Number of poles	3
Coil type	DC coil low consumption
Rated coil voltage	48 V DC
IEC operational current AC3	9 A
Motor power at 400 V AC3	4 kW
Thermal current AC1	20 A
Auxiliary contacts	1NC
Terminal type	Faston terminals
Mounting type	Screw mounting / DIN rail 35 mm
Rated insulation voltage	690 V
Horsepower rating at 480 V	5 HP
Protection rating	IP20 when installed
Mechanical life	approx. 20 million operations
Electrical life	approx. 500,000 operations
Operating temperature	approx. -40 °C to +60 °C
Dimensions	approx. 58 × 44 × 57 mm
Weight	approx. 224 g
EAN	8013975121184
Standards	IEC/EN 60947-1, IEC/EN 60947-4-1, UL 60947-1, UL 60947-4-1
Poles	3-pole
Coil / Supply Voltage	48 V DC
Device Type	Mini contactor
Auxiliary Contacts	1NC
Coil Type	DC
Current AC-1	20 A
