11BGP09T4A024 – MINICONTACTOR 4P NO 20A AC1 REAR PIN

Q: What coil voltage does this contactor use?

This contactor uses a 24V AC coil operating at 50/60Hz for compatible industrial control circuits.

Q: What current rating does the Lovato 11BGP09T4A024 support?

The contactor provides an IEC AC-3 operating current rating of 9A at 400V and an AC-1 thermal current rating of 20A.

Q: How many poles does this contactor have?

The Lovato 11BGP09T4A024 features four main poles for multi-circuit switching applications.

Lovato 11BGP09T4A024 four-pole miniature contactor with 24 V AC coil, 4NO contacts and 9 A AC3 operational current for industrial motor control and automation systems.

SKU: 11BGP09T4A024Alt SKU: BGP09T4A024MPN: 11BGP09T4A024

List Price £55.81 ex VAT

Your Price (ex VAT)

£55.81

Manufacturer Lead Time Please contact us for a delivery time before you order

Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Quantity:

SUBTOTAL (EX VAT) £55.81

Trade pricing is personalised to your account

Manufacturer Lead Time

£55.81

Why Choose the Lovato 11BGP09T4A024 Contactor?

The Lovato 11BGP09T4A024 is a compact and reliable four-pole industrial contactor designed for switching and controlling electrical loads in automation, machinery and industrial control applications. Part of the Lovato BGP series contactors, it delivers dependable electromagnetic switching performance, long service life and efficient integration into modern electrical systems.

This contactor features a 24V AC coil (50/60Hz), 4 main poles, an IEC AC-3 operating current rating of 9A at 400V and a compact rear PCB solder pin connection design. It is suitable for motor control and industrial switching applications where space-saving installation and reliable operation are required.

With its compact minicontactor format, screw and 35mm DIN rail mounting compatibility, the Lovato 11BGP09T4A024 is ideal for OEM machinery, automation panels and industrial control cabinets requiring efficient AC switching technology.

Key Advantages

Compact four-pole contactor for industrial switching applications.
24V AC coil voltage suitable for automation control circuits.
9A AC-3 rated current at 400V for motor switching applications.
20A AC-1 thermal current rating for general industrial loads.
Rear PCB solder pin connection for compact equipment designs.
Reliable switching performance with long mechanical and electrical life.

Key Features

Lovato BGP09 series industrial minicontactor.
Four main poles for multi-circuit switching applications.
24V AC electromagnetic coil operating at 50/60Hz.
9A IEC AC-3 operating current at 400V.
20A IEC AC-1 thermal current rating.
Rear PCB solder pin termination.
Screw and 35mm DIN rail mounting capability.
Suitable for industrial automation and motor control systems.

Reliable Switching for Industrial Control Systems

Industrial contactors such as the Lovato 11BGP09T4A024 provide efficient control of electrical circuits by using an electromagnetic coil to operate switching contacts. This enables reliable control of motors, machines and automation equipment.

The Lovato BGP series combines compact dimensions with robust electrical performance, making it suitable for machine builders, panel manufacturers and automation engineers who require dependable switching components for industrial environments.

Typical Applications

Industrial motor starters and control panels.
OEM machinery and automation equipment.
Conveyor and material handling systems.
Pumps, fans and mechanical drive applications.
Manufacturing and processing machinery.
Electrical cabinets and industrial automation systems.

Technical Specifications

Coil Voltage Range	24 V
Power	4 kW
Current	9 A
Voltage	24 V
Phase	Three Phase
Series	BG Mini Contactors
Product type	Four-pole miniature contactor
Number of poles	4
Main contact configuration	4NO
Rated operational current AC3	9 A
IEC thermal current AC1	20 A
Motor power at 400 V AC	4.0 kW
UL/CSA horsepower rating at 480 V	5 HP
Coil type	AC coil 50/60 Hz
Rated coil voltage	24 V AC
Rated insulation voltage	690 V
Mounting type	Screw / DIN rail 35 mm
Terminal type	Rear PCB solder pin
Operating temperature	-40 °C to +60 °C
Width	approx. 44 mm
Height	approx. 58 mm
Depth	approx. 57 mm
Weight	approx. 198 g
Standards	IEC/EN 60947-1, IEC/EN 60947-4-1, UL 60947-1, UL 60947-4-1
EAN	8013975145203
Poles	4-pole
Coil / Supply Voltage	24 V AC
Device Type	Mini contactor
Coil Type	AC
Current AC-1	20 A

Frequently Asked Questions

What is the Lovato 11BGP09T4A024 used for?

The Lovato 11BGP09T4A024 is a four-pole contactor used for switching motors and industrial electrical loads in automation and control systems.

What coil voltage does this contactor use?

This contactor uses a 24V AC coil operating at 50/60Hz for compatible industrial control circuits.

What current rating does the Lovato 11BGP09T4A024 support?

The contactor provides an IEC AC-3 operating current rating of 9A at 400V and an AC-1 thermal current rating of 20A.

How many poles does this contactor have?

The Lovato 11BGP09T4A024 features four main poles for multi-circuit switching applications.

How is the contactor installed?

The contactor supports screw mounting and 35mm DIN rail mounting, with rear PCB solder pin connections.

Trusted by Industrial Automation Professionals

Lovato contactors are widely used in industrial automation, machinery and electrical control applications where reliable switching performance, compact design and long service life are essential.

Coil Voltage Range	24 V
Power	4 kW
Current	9 A
Voltage	24 V
Phase	Three Phase
Series	BG Mini Contactors
Product type	Four-pole miniature contactor
Number of poles	4
Main contact configuration	4NO
Rated operational current AC3	9 A
IEC thermal current AC1	20 A
Motor power at 400 V AC	4.0 kW
UL/CSA horsepower rating at 480 V	5 HP
Coil type	AC coil 50/60 Hz
Rated coil voltage	24 V AC
Rated insulation voltage	690 V
Mounting type	Screw / DIN rail 35 mm
Terminal type	Rear PCB solder pin
Operating temperature	-40 °C to +60 °C
Width	approx. 44 mm
Height	approx. 58 mm
Depth	approx. 57 mm
Weight	approx. 198 g
Standards	IEC/EN 60947-1, IEC/EN 60947-4-1, UL 60947-1, UL 60947-4-1
EAN	8013975145203
Poles	4-pole
Coil / Supply Voltage	24 V AC
Device Type	Mini contactor
Coil Type	AC
Current AC-1	20 A
