11BGX78225 – NOISE FILTER BGX78 225V

Q: What voltage range does this surge suppressor support?

The unit is designed for DC coils from 0 to 225V DC.

Q: What type of suppression does the 11BGX78225 use?

The accessory uses a diode suppression circuit to reduce voltage spikes generated during coil switching.

Q: Which contactors are compatible with this accessory?

The Lovato 11BGX78225 is designed for use with Lovato BG series mini-contactors.

Q: How is the surge suppressor installed?

The accessory uses a quick connect mounting system for straightforward installation on compatible contactors.

Lovato 11BGX78225 quick connect surge suppressor with diode protection for BG series mini-contactors and DC coils up to 225 V DC.

SKU: 11BGX78225Alt SKU: BGX78225MPN: 11BGX78225

List Price £15.28 ex VAT

Your Price (ex VAT)

£15.28

Manufacturer Lead Time Please contact us for a delivery time before you order

Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Quantity:

SUBTOTAL (EX VAT) £15.28

Trade pricing is personalised to your account

Manufacturer Lead Time

£15.28

Why Choose the Lovato 11BGX78225 Surge Suppressor?

The Lovato 11BGX78225 is a compact quick connect surge suppressor designed for use with Lovato BG series mini-contactors. It provides coil voltage protection by suppressing transient voltage spikes generated when DC contactor coils are switched, helping improve reliability and extend the service life of electrical control components.

This accessory uses a diode suppression circuit and is suitable for DC coils up to 225V. The quick connect design allows simple installation directly onto compatible Lovato BG series mini-contactors, reducing wiring complexity and improving control panel efficiency.

The Lovato 11BGX78225 is ideal for industrial automation panels, motor control systems and OEM machinery where electromagnetic interference reduction and reliable contactor operation are required.

Key Advantages

Dedicated surge suppression accessory for Lovato BG series mini-contactors.
Diode suppression technology for DC coil protection.
Supports DC coil voltages up to 225V.
Quick connect installation reduces wiring time and simplifies assembly.
Helps reduce electrical noise and voltage transients in control circuits.
Compact design for industrial control panel integration.

Key Features

Lovato BG series contactor accessory.
Quick connect surge suppressor.
Diode protection circuit.
Rated voltage range: 0–225V DC.
Designed for 11BG series mini-contactors.
Reduces coil switching voltage peaks.
Improves reliability of automation control systems.

Improved Reliability for Industrial Control Systems

When DC contactor coils are switched off, stored magnetic energy can create voltage spikes that may affect nearby electronic components. Surge suppressors such as the Lovato 11BGX78225 help control these transient voltages, improving electromagnetic compatibility and system reliability.

The compact BG series accessory range allows machine builders and automation engineers to enhance contactor performance without requiring additional panel space or complex wiring modifications.

Typical Applications

Industrial automation control panels.
Motor starter assemblies.
OEM machinery control systems.
PLC-controlled switching applications.
Electrical cabinets and automation equipment.
Industrial motor control installations.

Technical Specifications

Coil Voltage Range	100–130 V, 12 V, 200–250 V, 24 V, 42–48 V, 60–72 V
Voltage	225 V
IP Rating	IP20
Series	BG Mini Contactor Accessories
Product type	Quick connect surge suppressor
Accessory type	Coil surge suppressor
Suppression type	Diode
Suitable coil type	DC coil
Rated coil voltage	0 to 225 V DC
Compatible series	Lovato BG mini-contactors
Mounting type	Quick connect / snap-on
Protection function	Voltage transient suppression
Degree of protection	IP20
Rated operating frequency	50 Hz
Maximum operating voltage	225 V
Weight	approx. 6.5 g
EAN	8013975080634
HS code	85365080
Standards	IEC/EN 60947-1, UL 60947-1, CSA C22.2 No. 60947-1
Certifications	cULus, EAC, RoHS compliant
Coil / Supply Voltage	225 V DC
Device Type	Accessory
Coil Type	DC

Frequently Asked Questions

What is the Lovato 11BGX78225 used for?

The Lovato 11BGX78225 is a quick connect surge suppressor used to protect DC coils on compatible Lovato BG series mini-contactors.

What voltage range does this surge suppressor support?

The unit is designed for DC coils from 0 to 225V DC.

What type of suppression does the 11BGX78225 use?

The accessory uses a diode suppression circuit to reduce voltage spikes generated during coil switching.

Which contactors are compatible with this accessory?

The Lovato 11BGX78225 is designed for use with Lovato BG series mini-contactors.

How is the surge suppressor installed?

The accessory uses a quick connect mounting system for straightforward installation on compatible contactors.
