1SAH100530R9900 ABB MCRI040ATD Mini Contactor Relay 4NO Control Relay

1SAH100530R9900 ABB MCRI040ATD Mini Contactor Relay 4NO Control Relay

ABB 1SAH100530R9900 MCRI040ATD is a compact PLC-controlled mini contactor relay with four normally open contacts and a low-consumption 24 V DC, 1.2 W coil.

SKU: 1SAH100530R9900Alt SKU: MCRI040ATDMPN: 1SAH100530R9900
Price
List Price £51.59 ex VAT
Your Price (ex VAT)
£51.59
Manufacturer Lead Time Estimated Delivery 7 weeks
Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Sign up for a trade account Quick & easy setup
SUBTOTAL (EX VAT) £51.59
Trade pricing is personalised to your account

Manufacturer Lead Time

£51.59

Why Choose the ABB 1SAH100530R9900 PLC-Controlled Mini Contactor Relay?

The ABB 1SAH100530R9900, also designated MCRI040ATD, is a compact four-pole mini contactor relay designed for switching control signals and small loads in industrial automation, machinery and building-control systems. Its low-consumption DC coil enables direct control from a compatible programmable logic controller.

This contactor relay incorporates four normally open auxiliary contacts and screw terminals for straightforward control-panel wiring. Its space-efficient construction delivers dependable switching performance where installation space is limited.

With a 24 V DC control coil consuming 1.2 W, the MCRI040ATD is suitable for direct PLC operation without an intermediate coupling relay where the PLC output has the required capacity. It supports AC-15 control loads up to 6 A at 240 V AC and can be installed on a DIN rail or mounting surface.

Key Advantages

  • Low-consumption 1.2 W coil supports direct PLC control.
  • Four normally open contacts for flexible signal switching.
  • Compact four-pole construction saves control-panel space.
  • 24 V DC control voltage suits industrial automation systems.
  • Screw terminals simplify installation and maintenance.
  • Suitable for DIN-rail or wall mounting.

Key Features

  • ABB MCRI mini contactor relay series.
  • 4NO auxiliary-contact configuration.
  • 24 V DC PLC-compatible control coil.
  • Coil holding and pull-in consumption of 1.2 W.
  • 6 A AC-15 rating at 240 V AC.
  • Rated auxiliary-circuit voltage of 690 V AC and 440 V DC.
  • Standard screw-terminal connections.
  • IP20 terminal protection.

Efficient Direct Control from PLC Outputs

A mini contactor relay uses an electromagnetic coil to change the state of its auxiliary contacts. The low-power coil in the ABB MCRI040ATD allows a compatible 24 V DC PLC output to operate the relay directly, helping reduce the need for intermediate coupling components.

The four normally open contacts can distribute control signals, operate auxiliary loads or provide interlocking within an automation system. Compact dimensions and flexible mounting make the relay suitable for densely populated control panels and machine-control assemblies.

Typical Applications

  • Direct switching from compatible PLC outputs.
  • Industrial machinery control circuits.
  • Electrical-panel relay logic and interlocking.
  • Automation and process-control systems.
  • Building-control and HVAC equipment.
  • OEM machinery and compact control assemblies.

Technical Specifications

Coil Voltage Range 24 V
Manufacturer ABB
Series MCRI Mini Contactor Relays
Model MCRI040ATD
Order code 1SAH100530R9900
Product type PLC-controlled mini contactor relay
Number of poles 4
Auxiliary contacts 4NO
Control voltage 24 V DC
Coil consumption 1.2 W holding and pull-in
Rated operational current, AC-15 at 240 V 6 A
Rated operational current, AC-15 at 400 V 4 A
Rated operational current, AC-15 at 500 V 2.5 A
Rated operational current, AC-15 at 690 V 1.5 A
Conventional free-air thermal current 10 A
Rated auxiliary-circuit operational voltage 690 V AC / 440 V DC
Rated insulation voltage 750 V
Rated impulse withstand voltage 6 kV
Mechanical durability 10,000,000 operating cycles
Terminal type Screw terminals
Protection rating IP20 at terminals
Mounting type DIN rail or wall mounting
Dimensions (W × H × D) 45 × 48 × 68 mm
Net weight 0.235 kg
Operating temperature -40 °C to +70 °C
Storage temperature -55 °C to +80 °C
Maximum operating altitude 3,000 m
Standards IEC/EN 60947-1, IEC/EN 60947-5-1, UL 60947-1 and UL 60947-5-1
Poles 4-pole
Coil / Supply Voltage 24 V DC
Device Type Contactor relay
Auxiliary Contacts 4NO
Coil Type DC
Current AC-1 10 A

Frequently Asked Questions

What is the ABB 1SAH100530R9900 used for?

It switches control signals and small loads in PLC-controlled machinery, automation systems and electrical control panels.

Can this mini contactor relay be controlled directly by a PLC?

Yes. Its 24 V DC, 1.2 W low-consumption coil is designed for direct operation from a compatible PLC output.

How many contacts does the MCRI040ATD have?

The relay has four normally open auxiliary contacts, providing a 4NO arrangement.

What is the AC-15 current rating?

The contactor relay is rated at 6 A at 240 V AC and 4 A at 400 V AC under the AC-15 utilisation category.

How is the ABB 1SAH100530R9900 installed?

The compact relay can be mounted on a compatible DIN rail or directly onto a mounting surface and connected through screw terminals.

Trusted ABB Control for PLC Automation

ABB MCRI mini contactor relays combine low coil consumption, compact construction and dependable switching to support efficient PLC-controlled machinery and industrial automation systems.
