1SAL103584R9902 ABB MC2C310ATD Mini Contactor Compact Control Contactor

1SAL103584R9902 ABB MC2C310ATD Mini Contactor Compact Control Contactor

ABB 1SAL103584R9902 MC2C310ATD mini contactor with three normally open main contacts, one normally closed auxiliary contact and 24 V DC coil supply for industrial switching applications.

SKU: 1SAL103584R9902Alt SKU: MC2C310ATDMPN: 1SAL103584R9902
Price
List Price £47.60 ex VAT
Your Price (ex VAT)
£47.60
Manufacturer Lead Time Estimated Delivery 5 weeks
Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Sign up for a trade account Quick & easy setup
SUBTOTAL (EX VAT) £47.60
Trade pricing is personalised to your account

Manufacturer Lead Time

£47.60

Why Choose the ABB 1SAL103584R9902 MC2C310ATD Mini Contactor?

The ABB 1SAL103584R9902 is a compact MC2C310ATD mini contactor designed for reliable switching of motors, electrical loads and control signals in residential, commercial and industrial applications. As part of the ABB M mini contactor range, it provides a space-saving solution where high performance and dependable DC-operated switching are required.

Featuring a 3-pole main contact configuration with 1 normally closed auxiliary contact, the MC2C310ATD is suitable for controlling single-phase and three-phase loads up to 5.5 kW at AC-3 and 20 A at 690 V AC-1. Its screw terminal connections and compact construction allow straightforward integration into automation systems and electrical control panels.

With a 24 V DC coil supply, the ABB 1SAL103584R9902 provides reliable contactor operation for machinery, automation equipment and industrial control systems where efficient use of installation space is important.

Key Advantages

  • Compact mini contactor designed for space-saving installations.
  • 3NO main contact configuration with 1NC auxiliary contact for flexible control applications.
  • 5.5 kW AC-3 motor switching capability at 400 V.
  • 20 A AC-1 rated current for general load switching.
  • 24 V DC coil operation for DC control systems.
  • Suitable for wall or rail mounting applications.

Key Features

  • ABB MC2C310ATD mini contactor.
  • 3 normally open main contacts.
  • 1 normally closed auxiliary contact.
  • 24 V DC coil voltage.
  • DC-operated contactor design.
  • Screw terminal connections.
  • Compact 45 mm wide construction.
  • Suitable for DIN rail and wall mounting.

Reliable Motor Switching for Compact Control Systems

Mini contactors provide efficient switching of motors, electrical loads and control circuits while reducing the space required inside electrical panels. Their compact design makes them ideal for automation systems, machinery and installations where reliable switching performance is required.

The ABB MC2C310ATD combines dependable DC switching performance with flexible installation options, allowing engineers and panel builders to create efficient control solutions in compact enclosures.

Typical Applications

  • Industrial automation control panels.
  • Small motor control systems.
  • Machine building applications.
  • DC control circuits.
  • Electrical switching assemblies.
  • Automation and process control systems.

Technical Specifications

Poles 3-pole
Power 5.5 kW
Current 12 A
Coil Voltage Range 24 V
Manufacturer ABB
Model 1SAL103584R9902
Product type Mini contactor
Series M mini contactors
Type code MC2C310ATD
Main contact configuration 3NO
Auxiliary contacts 1NC
Number of main poles 3
Coil / Supply Voltage 24 V DC
Rated operational current AC-1 20 A at 400 V
Rated operational current AC-3 12 A at 400 V
Rated operational power AC-3 5.5 kW at 400 V
Rated operational current AC-4 9 A at 400 V
Rated operational power AC-4 4 kW at 400 V
Rated insulation voltage 690 V
Mounting type Wall or rail mounting
Terminal type Screw terminals
Dimensions (H × W × D) 48 × 45 × 68 mm
Weight approx. 0.25 kg
EAN 4013614544989
Coil / Supply Voltage 24 V DC
Device Type Mini contactor
Auxiliary Contacts 1NC
Coil Type DC
Current AC-1 20 A

Frequently Asked Questions

What is the ABB 1SAL103584R9902 used for?

The ABB 1SAL103584R9902 is a mini contactor used for switching motors, electrical loads and control signals in industrial and automation applications.

What contact configuration does the MC2C310ATD provide?

The MC2C310ATD provides three normally open main contacts and one normally closed auxiliary contact.

What coil voltage does the ABB 1SAL103584R9902 require?

The contactor operates with a 24 V DC coil supply.

What motor power can the MC2C310ATD switch?

The contactor can switch motors up to 5.5 kW at 400 V AC-3.

How is the ABB MC2C310ATD installed?

The mini contactor supports wall or rail mounting and uses screw terminal connections.

Trusted for Compact Switching Solutions

ABB mini contactors provide reliable, space-saving switching solutions for automation engineers, machine builders and electrical system designers.
