ABB AS16-30-10-26 is a three-pole AC contactor rated at 15.5 A and 7.5 kW at 400 V, with a 230 V AC 50/60 Hz coil and one normally open auxiliary contact.
£72.75
The ABB AS16-30-10-26 is a compact three-pole AC-operated contactor designed for controlling three-phase motors, power circuits and non-inductive or slightly inductive loads. As part of the ABB AS contactor range, it combines three normally open main contacts with one built-in normally open auxiliary contact.
This contactor features a laminated magnet circuit and a 230 V AC, 50/60 Hz control coil for integration into industrial control systems. Its block-type construction provides a compact switching solution, while front-mounted add-on auxiliary contact blocks allow the control configuration to be expanded.
With an AC-3 operational current rating of 15.5 A at 380–415 V and a motor rating of 7.5 kW at 400 V, the AS16-30-10-26 is suitable for industrial motor switching and automation applications. Its 45 mm-wide enclosure and IP20 screw terminals support straightforward installation within electrical control panels.
Contactors such as the ABB AS16-30-10-26 provide electrically controlled switching for three-phase motors and other industrial power loads. The three normally open main poles switch the power circuit, while the built-in normally open auxiliary contact can support control, status-signalling and interlocking functions.
The AS series uses an AC-operated laminated magnet circuit and compact block-type construction. Compatibility with front-mounted auxiliary contact blocks allows the contactor to be adapted for more complex machine-control and automation arrangements.
| Manufacturer | ABB |
|---|---|
| Series | AS Contactors |
| Model | AS16-30-10-26 |
| Product ID | 1SBL121001R2610 |
| Product type | Three-pole AC-operated contactor |
| Main contacts | 3 NO, 0 NC |
| Auxiliary contacts | 1 NO, 0 NC |
| Rated control-circuit voltage | 230 V AC at 50/60 Hz |
| Rated operational voltage | Up to 690 V |
| Rated frequency | 50 / 60 Hz |
| AC-3 rated operational current | 15.7 A at 220–240 V; 15.5 A at 380–415 V; 13.6 A at 440 V; 12.5 A at 500 V; 9 A at 690 V |
| AC-3 rated operational power | 4 kW at 220–240 V; 7.5 kW at 400–690 V |
| AC-1 rated operational current | 24 A at 40 °C; 20 A at 60 °C; 16 A at 70 °C |
| Conventional free-air thermal current | 25 A at 40 °C |
| Rated insulation voltage | 690 V IEC; 600 V UL/CSA |
| Rated impulse withstand voltage | 6 kV |
| Terminal type | Screw terminals |
| Protection rating | IP20 |
| Standards | IEC 60947-1, IEC 60947-4-1, EN 60947-1, EN 60947-4-1, UL 508 and CSA C22.2 No. 14 |
| Maximum operating altitude | 3000 m |
| Dimensions (H × W × D) | 68 × 45 × 72.5 mm |
| Net weight | 0.22 kg |
This contactor is primarily used to control three-phase motors, power circuits and non-inductive or slightly inductive loads in industrial systems.
The AS16-30-10-26 is rated for AC-3 motor powers of 4 kW at 220–240 V and 7.5 kW at 400–690 V.
The contactor has an AC-operated coil rated for a 230 V AC, 50/60 Hz control supply.
The AS16-30-10-26 provides three normally open main contacts and one built-in normally open auxiliary contact.
The contactor uses screw terminals for its main, auxiliary and control circuits, with an IP20 degree of protection.
ABB AS contactors combine compact block-type construction, established IEC and UL/CSA compliance and flexible auxiliary-contact options for dependable motor and power-circuit switching in industrial control systems.
