Why Choose the Finder 22.34.0.024.4320 Modular Contactor?
The Finder 22.34.0.024.4320 is a compact and reliable four-pole modular contactor designed for switching lighting, heating, motor and building-automation loads. As part of the Finder 22 Series, it combines a 25 A contact rating with quiet AC/DC coil operation in a space-saving DIN-rail format.
This contactor provides four normally open contacts with silver tin oxide contact material, making it particularly suitable for lamp loads and circuits with high inrush currents. Double-break contacts and reinforced insulation between the coil and contacts support dependable switching and electrical separation.
With a 24 V AC/DC coil, integrated LED indication and a mechanical contact-position indicator, the 22.34.0.024.4320 provides clear operating feedback. Its 35 mm-wide enclosure mounts directly onto a standard DIN rail for straightforward integration into electrical distribution boards and control panels.
Key Advantages
- Compact four-pole modular contactor for electrical panels and distribution boards.
- 25 A rated contact current for demanding load-control applications.
- 24 V AC/DC coil supports both AC and DC control circuits.
- Silver tin oxide contacts are suitable for lamp loads and high inrush currents.
- Integrated LED and mechanical indicators provide clear operating feedback.
- Silent coil technology supports installation in noise-sensitive environments.
Key Features
- Finder 22 Series modular contactor.
- Four normally open contacts.
- 25 A rated current and 120 A maximum peak current.
- 24 V AC/DC coil supply.
- Silver tin oxide AgSnO2 contact material.
- Integrated LED status indicator.
- Integrated mechanical position indicator.
- Standard 35 mm DIN-rail mounting.
Reliable Switching for Lighting and Building Automation
Modular contactors allow lighting, heating, ventilation, pumps and other electrical loads to be controlled by timers, thermostats, programmable controllers and building-management systems. Their modular DIN-rail format makes them suitable for installation alongside other protective and control devices.
The Finder 22.34 uses silver tin oxide contacts to handle lamp loads and circuits with high starting currents. Its continuous-duty silent coil, LED indication and mechanical contact indicator make it well suited to automated installations where reliable operation and clear status information are required.
Typical Applications
- Commercial and industrial lighting control.
- LED, fluorescent and halogen lighting circuits.
- Heating and ventilation equipment.
- Pumps and small three-phase motors.
- Building-management and energy-control systems.
- Electrical distribution boards and automation panels.
