imo mb09-f-00230 mini contactor 3 pole n/o 4kw 9a ac3, fast-on connections 230vac

imo mb09-f-00230 mini contactor 3 pole n/o 4kw 9a ac3, fast-on connections 230vac

IMO MB09-F-00230 miniature contactor with 9A AC-3 rating, 4 kW motor capacity, 230 V AC coil and Fast-On terminal connections for industrial motor control and automation systems.

SKU: MB09-F-00230Alt SKU: MB09F00230MPN: MB09-F-00230
Price
List Price £32.06 ex VAT
Your Price (ex VAT)
£32.06
Manufacturer Lead Time Please contact us for a delivery time before you order
Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Sign up for a trade account Quick & easy setup
SUBTOTAL (EX VAT) £32.06
Trade pricing is personalised to your account

Manufacturer Lead Time

£32.06

Why Choose the IMO MB09-F-00230 Mini Contactor?

The IMO MB09-F-00230 is a compact and reliable miniature contactor designed for industrial motor switching and automation control applications. Manufactured by IMO Precision Controls, this industrial contactor delivers dependable switching performance for machinery, control systems and OEM automation equipment. Its Fast-On terminal connections provide rapid installation and simplified wiring for efficient panel assembly.

Designed for demanding industrial motor control duties, the MB09-F-00230 provides a robust 9 A AC-3 operational rating suitable for switching three-phase motors and industrial electrical loads. The compact housing helps maximise available panel space while maintaining reliable long-term operational performance in industrial environments.

Featuring a 230 V AC operating coil, 3-pole normally open contacts and Fast-On terminal connections, this miniature contactor is ideal for motor starters, conveyor systems, HVAC equipment and industrial automation systems requiring compact and dependable switching solutions.

Key Advantages

  • Compact miniature contactor for industrial automation systems.
  • 9 A AC-3 operational rating suitable for motor switching applications.
  • Supports motors up to approximately 4 kW.
  • 230 V AC operating coil compatible with industrial control systems.
  • Fast-On terminal connections simplify installation and wiring.
  • Compact industrial enclosure saves valuable panel space.

Key Features

  • IMO MB miniature contactor series.
  • 3-pole normally open main contacts.
  • 9 A AC-3 current rating.
  • 4 kW motor power capability.
  • 230 V AC coil voltage.
  • Fast-On terminal configuration.
  • Compact industrial housing for OEM integration.
  • Designed for industrial motor control applications.

Reliable Industrial Motor Switching

Miniature contactors such as the IMO MB09-F-00230 are widely used in industrial automation systems to safely switch motors, compressors, pumps and electrical loads. Their compact dimensions make them ideal for electrical control cabinets and OEM machinery where space efficiency and fast installation are important.

The IMO MB series is engineered for dependable switching performance and long operational life in demanding industrial environments. The Fast-On terminal arrangement allows quick electrical connection while supporting efficient panel assembly and maintenance operations.

Typical Applications

  • Industrial motor starters.
  • Automation control systems.
  • HVAC and ventilation equipment.
  • Pumps and compressor control circuits.
  • Conveyor systems and material handling.
  • OEM machinery and production equipment.

Technical Specifications

Poles 3-pole
Coil Voltage Range 200–250 V
Power 4 kW
Current 9 A
Voltage 230 V
Phase Three Phase
Series MB Miniature Contactors
Product type Miniature contactor
Main contact configuration 3 pole normally open
Rated operational current 9 A AC-3
Motor rating 4 kW at 400 V AC
Coil / Supply Voltage 230 V AC
Frequency 50 / 60 Hz
Connection type Fast-On terminals
Rated insulation voltage 690 V AC
Mechanical life Approx. 5 million operations
Standards EN 60947-4-1
HS Code 8536490099
Country of Manufacture Austria
Coil / Supply Voltage 230 V AC
Device Type Mini contactor
Coil Type AC

Frequently Asked Questions

What is the IMO MB09-F-00230 used for?

This miniature contactor is used for switching motors and electrical loads in industrial automation and machine control systems.

What current rating does this contactor provide?

The contactor has a 9 A AC-3 operational current rating suitable for industrial motor control applications.

What motor size can this contactor control?

The MB09-F-00230 is suitable for motors up to approximately 4 kW at 400 V AC.

What coil voltage does the MB09-F-00230 use?

This model operates using a 230 V AC control coil.

What connection type does this contactor use?

The MB09-F-00230 uses Fast-On terminal connections for rapid installation and simplified wiring.
