IMO VXR-EFC encoder feedback interface card for IMO Jaguar VXR inverter drives, supporting 12 V encoder systems, vector control and positioning applications.
£109.00
The IMO VXR-EFC is an optional 12 V encoder feedback board designed specifically for compatible IMO VXR variable frequency drives. It enables closed-loop motor control by accepting incremental encoder feedback, providing improved speed regulation, enhanced low-speed torque and accurate motor positioning for demanding industrial applications.
Designed as a simple plug-in expansion module, the VXR-EFC integrates directly with supported IMO VXR drives, allowing machine builders and automation engineers to upgrade standard inverter performance with precise encoder feedback. Closed-loop operation delivers greater process stability, improved dynamic response and higher accuracy under varying load conditions.
Suitable for conveyors, hoists, winding machinery, printing equipment and other precision automation systems, the IMO VXR-EFC provides dependable encoder feedback while maintaining seamless compatibility with the IMO VXR drive platform.
Encoder feedback continuously provides motor speed and position information to the drive, allowing closed-loop vector control for improved speed accuracy, enhanced torque at low speeds and rapid response to changing load conditions. This results in smoother machine operation and improved production quality.
The IMO VXR-EFC is ideal for applications requiring accurate synchronisation, positioning and speed regulation, making it suitable for a wide range of industrial automation systems.
| Series | Jaguar VXR |
|---|---|
| Product type | Encoder feedback interface card |
| Encoder voltage compatibility | 12 V encoder systems |
| Compatible products | IMO Jaguar VXR inverter drives |
| Supported encoder channels | A, -A, B, -B, Z and -Z |
| Encoder resolution support | approx. 20–3000 ppr |
| Maximum pulse frequency | 400 kHz |
| Control functions | Speed control, positioning control, vector control |
| Application | Closed-loop motor feedback and positioning |
| Mounting method | Plug-in option card |
| Industrial use | Automation and motor control systems |
| Positioning capability | Supported |
| Pulse train input | Supported |
It adds 12 V encoder feedback capability to compatible IMO VXR variable frequency drives, enabling accurate closed-loop motor control.
The module supports compatible 12 V incremental encoders with resolutions from approximately 20 to 3000 pulses per revolution.
The VXR-EFC is designed specifically for supported IMO VXR variable frequency drives.
Encoder feedback improves speed regulation, positioning accuracy, low-speed torque and overall motor control performance.
Yes. The VXR-EFC installs internally as an optional encoder feedback expansion board for compatible IMO VXR drives.
IMO encoder feedback modules help industrial engineers achieve accurate closed-loop motor control, improved machine performance and reliable operation across demanding automation applications.
