11RF9023 - T/O RELAY RF9 0.14-0.23A

11RF9023 – T/O RELAY RF9 0.14-0.23A

Lovato 11RF9023 is a three-pole, manually reset thermal motor protection relay with a 0.14–0.23 A adjustable current range, phase-failure sensitivity and direct mounting on BG06, BG09 and BG12 mini-contactors.

SKU: 11RF9023Alt SKU: RF9023MPN: 11RF9023
Price
List Price £60.43 ex VAT
Your Price (ex VAT)
£60.43
Manufacturer Lead Time Please contact us for a delivery time before you order
Get the best trade prices Trade exclusive

Create a trade account to unlock exclusive pricing, special offers and more.

Sign up for a trade account Quick & easy setup
SUBTOTAL (EX VAT) £60.43
Trade pricing is personalised to your account

Manufacturer Lead Time

£60.43

Why Choose the Lovato 11RF9023 Motor Protection Relay?

The Lovato 11RF9023 is a three-pole thermal motor protection relay designed to protect three-phase motors against overload and phase-failure conditions. Its adjustable operational current range of 0.14–0.23 A enables accurate protection of low-current motor circuits.

This phase-failure-sensitive relay features manual resetting, tripping class 10A, a test button and a visible trip indicator. One normally open and one normally closed auxiliary contact are included for signalling and integration with control circuits.

The 11RF9023 mounts directly onto Lovato BG06, BG09 and BG12 mini-contactors, supporting compact motor starter assemblies. Its 690 V rated operational voltage, IP20 frontal protection and broad operating-frequency range make it suitable for industrial control panels and machinery.

Key Advantages

  • Adjustable 0.14–0.23 A operational current range.
  • Thermal overload and phase-failure protection for three-phase motors.
  • Direct mounting on BG06, BG09 and BG12 mini-contactors.
  • Manual reset helps prevent unintended automatic restarting.
  • Integrated test button and visible trip indicator.
  • One normally open and one normally closed auxiliary contact.

Key Features

  • Lovato 11RF9 motor protection relay series.
  • Three-pole thermal release.
  • 0.14–0.23 A adjustable operational current.
  • Tripping class 10A.
  • Phase-failure-sensitive operation.
  • 690 V rated operational voltage.
  • Manual reset, test button and trip indicator.
  • 1 NO and 1 NC auxiliary contact.
  • Direct mounting on Lovato BG-series mini-contactors.
  • IP20 frontal protection.

Reliable Protection for Three-Phase Motors

Thermal motor protection relays monitor the current supplied to a motor and trip when a sustained overload creates a potentially damaging condition. Phase-failure sensitivity adds protection when one phase is lost, helping reduce the risk of motor overheating and premature equipment failure.

The Lovato 11RF9023 combines an adjustable current setting with manual reset, auxiliary signalling contacts and direct contactor mounting. These features support compact, coordinated motor starter assemblies that are straightforward to test, monitor and maintain.

Typical Applications

  • Protection of low-current three-phase motors.
  • Motor starters using Lovato BG06 mini-contactors.
  • Motor starters using Lovato BG09 mini-contactors.
  • Motor starters using Lovato BG12 mini-contactors.
  • Industrial machinery and automation systems.
  • Electrical control panels and compact switchgear assemblies.

Technical Specifications

Tick the specs you need, then view products that match.

Load Voltage 690 V
Monitoring Function Temperature / thermistor
Monitored Supply Single-phase
Reset Type Manual
Manufacturer Lovato Electric
Series 11RF9
Model 11RF9023
Product type Thermal motor protection relay
Number of poles 3
Operational current 0.14–0.23 A
Type of release Thermal
Tripping class 10A
Phase-failure detection Yes
Reset mode Manual
Rated operational voltage 690 V
Rated insulation voltage 690 V
Rated impulse withstand voltage 8 kV
Operational frequency 0–400 Hz
Recommended aM protection fuse 0.5 A
Recommended UL RK5 protection fuse 1 A
Auxiliary contacts 1 NO + 1 NC
Frontal protection rating IP20
Overvoltage category III
Pollution degree 3
Power terminal type Screw and washer, M4
Power terminal tightening torque 2.3 Nm
Operating temperature -20 to +55 °C
Storage temperature -55 to +70 °C
Maximum altitude 3000 m
Mounting type Direct mounting on BG06, BG09 and BG12 mini-contactors
Normal operating position Vertical plane
Weight 116 g
Contacts 1NO + 1NC

Frequently Asked Questions

What is the Lovato 11RF9023 used for?

The Lovato 11RF9023 protects three-phase motors against thermal overload and phase-failure conditions in compatible motor starter assemblies.

What is the current adjustment range of the 11RF9023?

The relay has an adjustable operational current range of 0.14–0.23 A.

Which contactors are compatible with the Lovato 11RF9023?

The relay is designed for direct mounting on Lovato BG06, BG09 and BG12 mini-contactors.

Does the 11RF9023 detect phase failure?

Yes. The 11RF9023 is phase-failure sensitive and helps protect a three-phase motor if one of its supply phases is lost.

How is the Lovato 11RF9023 reset after tripping?

The relay uses manual resetting and also includes a test button and visual trip indicator.

Trusted Motor Protection from Lovato Electric

Lovato thermal motor protection relays provide dependable overload and phase-failure protection for industrial motors, combining adjustable settings, control-circuit signalling and direct integration with compatible contactors.
