Lovato 11RFA9023 is a three-pole thermal motor protection relay with a 0.14–0.23 A adjustable current range, automatic reset and phase failure sensitivity for direct mounting on BG06, BG09 and BG12 mini-contactors.
£73.99
The Lovato 11RFA9023 is a compact and reliable thermal motor protection relay designed to protect three-phase motors against overload and phase failure conditions. Part of the Lovato 11RFA9 series, it features phase failure and single-phase sensitivity together with automatic resetting for dependable motor protection in industrial control applications.
Designed for direct mounting on Lovato BG06, BG09 and BG12 mini-contactors, the 11RFA9023 provides a space-efficient motor starter solution without requiring separate relay mounting. Its thermal release mechanism, Class 10A tripping characteristic, test button and trip indicator provide practical protection and straightforward system monitoring.
With an adjustable operational current range of 0.14–0.23 A and a rated operational voltage of up to 690 V, the 11RFA9023 is suitable for protecting small three-phase motors. Its IP20 frontal protection and robust industrial design support reliable operation in control panels and machinery applications.
Thermal overload relays such as the Lovato 11RFA9023 protect electric motors by responding to sustained overcurrent conditions that can cause overheating and equipment damage. Phase failure sensitivity provides additional protection when one phase of a three-phase supply is lost, helping reduce the risk of abnormal motor operation.
The 11RFA9023 is designed to integrate directly with compatible Lovato BG mini-contactors, creating a compact motor starter assembly. Its automatic reset function, trip indication and test facility make it well suited to industrial machinery, automation equipment and control-panel applications where dependable motor protection is required.
| Manufacturer | Lovato Electric |
|---|---|
| Series | 11RFA9 |
| Model | 11RFA9023 |
| Product type | Thermal motor protection relay |
| Number of poles | 3 |
| Operational current | 0.14–0.23 A |
| Rated operational voltage | 690 V |
| Rated insulation voltage Ui | 690 V |
| Rated impulse withstand voltage Uimp | 8 kV |
| Operational frequency | 0–400 Hz |
| Tripping class | 10A |
| Reset mode | Automatic |
| Phase failure detection | Yes |
| Protection rating | IP20 frontal |
| Auxiliary contacts | 1 NO + 1 NC |
| Main terminal type | Screw and washer |
| Operating temperature | -20 to 55 °C |
| Storage temperature | -55 to 70 °C |
| Maximum altitude | 3000 m |
| Mounting type | Direct mounting on BG06, BG09 and BG12 mini-contactors |
| Weight | 115 g |
The Lovato 11RFA9023 is a thermal overload relay used to protect three-phase motors against overload and phase failure conditions.
The relay has an adjustable operational current range of 0.14–0.23 A.
Yes. The 11RFA9023 uses an automatic reset mode.
The relay is designed for direct mounting on Lovato BG06, BG09 and BG12 mini-contactors.
Yes. The relay is phase failure and single-phase sensitive, providing additional protection for three-phase motors.
Lovato Electric motor protection relays are engineered for dependable integration with industrial motor starters, helping protect motors against overload and phase failure while supporting compact and reliable control-panel designs.{ "@context": "https://schema.org/", "@type": "Product", "name": "Lovato 11RFA9023 Thermal Overload Relay 0.14–0.23 A", "sku": "11RFA9023", "mpn": "11RFA9023", "brand": { "@type": "Brand", "name": "Lovato Electric" }, "category": "Thermal Overload Relays", "description": "Lovato 11RFA9023 is a three-pole thermal motor protection relay with a 0.14–0.23 A adjustable current range, automatic reset and phase failure sensitivity for direct mounting on BG06, BG09 and BG12 mini-contactors.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Operational current", "value": "0.14–0.23 A" }, { "@type": "PropertyValue", "name": "Rated operational voltage", "value": "690 V" }, { "@type": "PropertyValue", "name": "Reset mode", "value": "Automatic" }, { "@type": "PropertyValue", "name": "Tripping class", "value": "10A" }, { "@type": "PropertyValue", "name": "Protection rating", "value": "IP20 frontal" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What is the Lovato 11RFA9023 used for?", "acceptedAnswer": { "@type": "Answer", "text": "The Lovato 11RFA9023 is a thermal overload relay used to protect three-phase motors against overload and phase failure conditions." } }, { "@type": "Question", "name": "What current range does the 11RFA9023 support?", "acceptedAnswer": { "@type": "Answer", "text": "The relay has an adjustable operational current range of 0.14–0.23 A." } }, { "@type": "Question", "name": "Does the Lovato 11RFA9023 reset automatically?", "acceptedAnswer": { "@type": "Answer", "text": "Yes. The 11RFA9023 uses an automatic reset mode." } }, { "@type": "Question", "name": "Which contactors can the 11RFA9023 be mounted on?", "acceptedAnswer": { "@type": "Answer", "text": "The relay is designed for direct mounting on Lovato BG06, BG09 and BG12 mini-contactors." } }, { "@type": "Question", "name": "Does the 11RFA9023 detect phase failure?", "acceptedAnswer": { "@type": "Answer", "text": "Yes. The relay is phase failure and single-phase sensitive, providing additional protection for three-phase motors." } } ] }
