Lovato 11RFNA910 is a three-pole Class 10A thermal motor protection relay with a 6–10 A adjustable operational current range, automatic resetting and direct mounting on BG06, BG09 and BG12 mini-contactors.
£74.48
The Lovato 11RFNA910 is a three-pole thermal motor protection relay designed for direct mounting on Lovato BG06, BG09 and BG12 mini-contactors. With an adjustable operational current range of 6–10 A, it provides thermal overload protection for compatible three-phase motor control applications.
Part of the Lovato RFNA9 motor protection relay series, the 11RFNA910 features automatic resetting, a test button and a trip indicator. The relay is specified as non-phase-failure/non-single-phase-sensitive and incorporates one normally open and one normally closed auxiliary contact for integration into motor control circuits.
With a 690 V rated operational voltage, 690 V rated insulation voltage and 8 kV rated impulse withstand voltage, the 11RFNA910 is designed for industrial motor protection systems. Its Class 10A tripping characteristic and compact direct-mounting format make it suitable for motor starters built around compatible Lovato BG mini-contactors.
Thermal overload relays protect motors against sustained overcurrent conditions that can cause excessive heating. The relay monitors motor current and, when an overload persists according to its tripping characteristic, changes the state of its auxiliary contacts so the associated control circuit can disconnect the motor.
The Lovato 11RFNA910 combines a 6–10 A adjustable current range with Class 10A tripping and automatic resetting. Direct mounting on compatible BG06, BG09 and BG12 mini-contactors enables compact motor starter assemblies for industrial machinery and control-panel applications.
| Manufacturer | Lovato Electric |
|---|---|
| Series | RFNA9 |
| Model | 11RFNA910 |
| Product type | Thermal motor protection relay |
| Number of poles | 3 |
| Release type | Thermal |
| Operational current range | 6–10 A |
| Tripping class | 10A |
| Reset mode | Automatic |
| Test button | Yes |
| Trip indicator | Yes |
| Auxiliary contacts | 1 NO + 1 NC |
| Rated operational voltage | 690 V |
| Rated insulation voltage (Ui) | 690 V |
| Rated impulse withstand voltage (Uimp) | 8 kV |
| Operational frequency | 0–400 Hz |
| Conventional free-air thermal current (Ith) | 10 A at ≤40 °C |
| Frontal protection rating | IP20 |
| Overvoltage category | III |
| Pollution degree | 3 |
| Power terminal type | Screw and washer |
| Power terminal screw | M4 |
| Power terminal tightening torque | 2.3 Nm |
| Operating temperature | -20 to +55 °C |
| Storage temperature | -55 to +70 °C |
| Maximum altitude | 3000 m |
| Mounting | Direct mounting on BG06, BG09 and BG12 mini-contactors |
| Weight | 116 g |
| Package dimensions | 65 × 46 × 90 mm |
| Package volume | 269.1 cm³ |
| Quantity per package | 1 |
| EAN13 | 8013975020661 |
| HS code | 85364900 |
The Lovato 11RFNA910 has an adjustable operational current range of 6–10 A.
The 11RFNA910 is designed for direct mounting on Lovato BG06, BG09 and BG12 mini-contactors.
Yes. The 11RFNA910 uses an automatic reset mode and also incorporates a test button and trip indicator.
The Lovato 11RFNA910 is a Class 10A thermal motor protection relay.
The 11RFNA910 incorporates one normally open and one normally closed auxiliary contact for use within the motor control circuit.
Lovato RFNA9 thermal overload relays provide compact motor protection for compatible BG mini-contactor assemblies, combining adjustable thermal overload protection with automatic resetting, test functionality and trip indication.{ "@context": "https://schema.org/", "@type": "Product", "name": "Lovato 11RFNA910 RFNA9 Thermal Overload Relay 6–10 A", "sku": "11RFNA910", "mpn": "11RFNA910", "brand": { "@type": "Brand", "name": "Lovato Electric" }, "category": "Thermal Overload Relays", "description": "Lovato 11RFNA910 is a three-pole Class 10A thermal motor protection relay with a 6–10 A adjustable operational current range, automatic resetting and direct mounting on BG06, BG09 and BG12 mini-contactors.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Operational current range", "value": "6–10 A" }, { "@type": "PropertyValue", "name": "Number of poles", "value": "3" }, { "@type": "PropertyValue", "name": "Tripping class", "value": "10A" }, { "@type": "PropertyValue", "name": "Reset mode", "value": "Automatic" }, { "@type": "PropertyValue", "name": "Auxiliary contacts", "value": "1 NO + 1 NC" }, { "@type": "PropertyValue", "name": "Rated operational voltage", "value": "690 V" }, { "@type": "PropertyValue", "name": "Frontal protection rating", "value": "IP20" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What current range does the Lovato 11RFNA910 cover?", "acceptedAnswer": { "@type": "Answer", "text": "The Lovato 11RFNA910 has an adjustable operational current range of 6–10 A." } }, { "@type": "Question", "name": "Which contactors are compatible with the Lovato 11RFNA910?", "acceptedAnswer": { "@type": "Answer", "text": "The 11RFNA910 is designed for direct mounting on Lovato BG06, BG09 and BG12 mini-contactors." } }, { "@type": "Question", "name": "Does the Lovato 11RFNA910 reset automatically?", "acceptedAnswer": { "@type": "Answer", "text": "Yes. The 11RFNA910 uses an automatic reset mode and also incorporates a test button and trip indicator." } }, { "@type": "Question", "name": "What tripping class does the 11RFNA910 use?", "acceptedAnswer": { "@type": "Answer", "text": "The Lovato 11RFNA910 is a Class 10A thermal motor protection relay." } }, { "@type": "Question", "name": "What auxiliary contacts does the Lovato 11RFNA910 include?", "acceptedAnswer": { "@type": "Answer", "text": "The 11RFNA910 incorporates one normally open and one normally closed auxiliary contact for use within the motor control circuit." } } ] }
