Lovato 11RFNA95 is a three-pole Class 10A thermal overload relay with a 3–5 A adjustable operational current range, automatic resetting and direct mounting on BG06, BG09 and BG12 mini-contactors.
£74.48
The Lovato 11RFNA95 is a three-pole thermal motor protection relay designed for direct mounting on Lovato BG06, BG09 and BG12 mini-contactors. With an adjustable operational current range of 3–5 A, it provides thermal overload protection for compatible three-phase motor control applications.
Part of the Lovato RFNA9 motor protection relay series, the 11RFNA95 is a non-phase-failure/non-single-phase-sensitive relay with automatic resetting. Its compact direct-mounting arrangement makes it suitable for motor starters and control panels based on compatible Lovato BG mini-contactors.
The relay features a Class 10A tripping characteristic, a maximum rated operational voltage of 690 V and 1 NO + 1 NC auxiliary contacts. Screw-connected main circuit terminals and IP20 frontal protection support straightforward integration into industrial motor control equipment.
Thermal overload relays are used in motor control circuits to respond to sustained overcurrent conditions that can cause excessive motor heating. An adjustable current range enables the overload setting to be matched to the operating current of the connected motor.
The Lovato 11RFNA95 combines a 3–5 A adjustable current range with Class 10A tripping and automatic resetting. Its direct mounting on compatible BG06, BG09 and BG12 mini-contactors enables compact motor starter assemblies for industrial machinery, automation systems and electrical control panels.
| Manufacturer | Lovato Electric |
|---|---|
| Series | RFNA9 |
| Model | 11RFNA95 |
| Product type | Thermal overload relay |
| Number of poles | 3 |
| Operational current range | 3–5 A |
| Tripping class | Class 10A |
| Reset mode | Automatic |
| Phase failure sensitivity | Non-phase-failure/non-single-phase-sensitive |
| Auxiliary contacts | 1 NO + 1 NC |
| Auxiliary contact thermal current | 10 A |
| Maximum rated operational voltage | 690 V |
| Frontal protection rating | IP20 |
| Main circuit connection | Screw connection |
| Mounting type | Direct mounting |
| Compatible contactors | BG06, BG09 and BG12 |
| Operating temperature | -20 to +55 °C |
| Weight | 113 g |
| Package dimensions | 65 × 46 × 90 mm |
| Package volume | 269.1 cm³ |
| Quantity per package | 1 |
| EAN13 | 8013975020715 |
| HS code | 85364900 |
| Conformity | IEC/EN 60947-1, IEC/EN 60947-4-1, UL 508, CSA |
The Lovato 11RFNA95 has an adjustable operational current range of 3–5 A.
The 11RFNA95 is designed for direct mounting on Lovato BG06, BG09 and BG12 mini-contactors.
Yes. The 11RFNA95 is specified with an automatic reset function.
The Lovato 11RFNA95 has a Class 10A tripping characteristic.
The 11RFNA95 incorporates one normally open and one normally closed auxiliary contact.
Lovato RFNA9 thermal overload relays provide compact motor protection for compatible BG mini-contactor assemblies, combining adjustable thermal overload protection with automatic resetting and direct mounting.{ "@context": "https://schema.org/", "@type": "Product", "name": "Lovato 11RFNA95 RFNA9 Thermal Overload Relay 3–5 A", "sku": "11RFNA95", "mpn": "11RFNA95", "brand": { "@type": "Brand", "name": "Lovato Electric" }, "category": "Thermal Overload Relays", "description": "Lovato 11RFNA95 is a three-pole Class 10A thermal overload relay with a 3–5 A adjustable operational current range, automatic resetting and direct mounting on BG06, BG09 and BG12 mini-contactors.", "additionalProperty": [ { "@type": "PropertyValue", "name": "Operational current range", "value": "3–5 A" }, { "@type": "PropertyValue", "name": "Number of poles", "value": "3" }, { "@type": "PropertyValue", "name": "Tripping class", "value": "Class 10A" }, { "@type": "PropertyValue", "name": "Reset mode", "value": "Automatic" }, { "@type": "PropertyValue", "name": "Auxiliary contacts", "value": "1 NO + 1 NC" }, { "@type": "PropertyValue", "name": "Maximum rated operational voltage", "value": "690 V" }, { "@type": "PropertyValue", "name": "Frontal protection rating", "value": "IP20" } ] } { "@context": "https://schema.org", "@type": "FAQPage", "inLanguage": "en-GB", "mainEntity": [ { "@type": "Question", "name": "What current range does the Lovato 11RFNA95 cover?", "acceptedAnswer": { "@type": "Answer", "text": "The Lovato 11RFNA95 has an adjustable operational current range of 3–5 A." } }, { "@type": "Question", "name": "Which contactors are compatible with the Lovato 11RFNA95?", "acceptedAnswer": { "@type": "Answer", "text": "The 11RFNA95 is designed for direct mounting on Lovato BG06, BG09 and BG12 mini-contactors." } }, { "@type": "Question", "name": "Does the Lovato 11RFNA95 reset automatically?", "acceptedAnswer": { "@type": "Answer", "text": "Yes. The 11RFNA95 is specified with an automatic reset function." } }, { "@type": "Question", "name": "What tripping class does the Lovato 11RFNA95 use?", "acceptedAnswer": { "@type": "Answer", "text": "The Lovato 11RFNA95 has a Class 10A tripping characteristic." } }, { "@type": "Question", "name": "What auxiliary contacts does the Lovato 11RFNA95 include?", "acceptedAnswer": { "@type": "Answer", "text": "The 11RFNA95 incorporates one normally open and one normally closed auxiliary contact." } } ] }
