Why Choose the Lovato SM1X16024 Shunt Trip Release?
The Lovato SM1X16024 is a compact and dependable shunt trip release designed for use with Lovato SM1P and SM1R motor protection circuit breakers. It enables remote electrical tripping of compatible devices, making it ideal for safety, emergency stop and control circuit applications in industrial motor protection systems.
Operating from a 24 V AC 50/60 Hz control supply, the SM1X16024 provides reliable remote opening functionality for control panels, machinery and automation systems. It is particularly useful where a motor protection circuit breaker must be tripped from an external signal, safety circuit or supervisory control system.
Designed as a manufacturer-matched accessory for the Lovato SM1 series, this shunt trip release integrates neatly with compatible motor protection circuit breakers while maintaining a compact panel layout. It supports safe and efficient operation in OEM equipment, motor starter assemblies and industrial control installations.
Key Advantages
- Compact shunt trip release for Lovato SM1 motor protection circuit breakers.
- 24 V AC 50/60 Hz operating voltage for control circuits.
- Allows remote electrical tripping of compatible protection devices.
- Suitable for emergency stop, safety and automation control applications.
- Designed for compatible SM1P and SM1R devices.
- Ideal for industrial control panels and motor starter assemblies.
Key Features
- Lovato SM1X accessory series.
- Shunt trip release module.
- 24 V AC 50/60 Hz rated control supply.
- Compatible with SM1P and SM1R motor protection circuit breakers.
- Designed for remote opening and trip control.
- Suitable for safety and supervisory control circuits.
- Compact construction for panel integration.
- Supplied as a single accessory unit.
Reliable Remote Tripping for Motor Protection Circuits
A shunt trip release allows a motor protection circuit breaker to be opened electrically from a remote control signal. This is useful in emergency stop circuits, interlocked machinery systems and control panels where electrical disconnection must be triggered without manual operation at the breaker.
The Lovato SM1X16024 provides this remote trip functionality for compatible SM1 motor protection circuit breakers, helping panel builders and automation engineers improve safety, control flexibility and integration with wider machine control systems.
Typical Applications
- Industrial motor starter panels.
- Emergency stop and safety circuits.
- Machine building and OEM equipment.
- Remote trip and control systems.
- Industrial automation control panels.
- Motor protection installations using SM1P and SM1R devices.
