Why Choose the Lovato SM1X16400 Shunt Trip Release?
The Lovato SM1X16400 is a robust shunt trip release designed for use with Lovato SM1P and SM1R motor protection circuit breakers. It provides reliable remote electrical tripping, allowing compatible motor protection devices to be opened instantly from an external control signal for enhanced machine safety and process control.
Operating from a 400 V AC 50/60 Hz control supply, the SM1X16400 is ideal for industrial installations where remote disconnection is required through emergency stop circuits, PLCs, fire protection systems or other supervisory control equipment. Its compact construction ensures simple installation while maintaining a tidy control panel layout.
Designed specifically for the Lovato SM1 range, this accessory delivers dependable operation, long mechanical life and straightforward integration into industrial motor control systems, making it an excellent choice for OEM machinery, manufacturing equipment and automation panels.
Key Advantages
- Compact shunt trip release for Lovato SM1 motor protection circuit breakers.
- 400 V AC 50/60 Hz operating voltage.
- Allows remote electrical tripping of compatible protection devices.
- Suitable for emergency stop, machine safety and automation systems.
- Designed for compatible SM1P and SM1R motor protection circuit breakers.
- Simple direct mounting for industrial control panels.
Key Features
- Lovato SM1X accessory series.
- Shunt trip release module.
- 400 V AC 50/60 Hz rated control supply.
- Compatible with SM1P and SM1R motor protection circuit breakers.
- Designed for remote electrical opening.
- 690 V rated insulation voltage (Ui).
- 4 kV impulse withstand voltage (Uimp).
- 100,000 mechanical operating cycles.
Reliable Remote Tripping for Industrial Motor Protection
A shunt trip release enables a motor protection circuit breaker to be opened remotely by applying an electrical control signal. This functionality is widely used in emergency stop circuits, machine safety systems, PLC-controlled processes and fire protection interfaces where immediate electrical isolation is required.
The Lovato SM1X16400 has been engineered for dependable operation in demanding industrial environments, providing reliable remote tripping while integrating seamlessly with compatible SM1 motor protection circuit breakers.
Typical Applications
- Industrial motor starter panels.
- Emergency stop systems.
- Machine safety circuits.
- Industrial automation and PLC control.
- Remote motor protection control.
- OEM machinery and production equipment.
