Why Choose the ABB P9PDNF0 Lamp Block?
The ABB P9PDNF0 is a full-voltage lamp block with Faston terminals from the ABB P9M modular metal pilot-device range. Supplied under ABB order code 1SFA187055R1300, it provides the illumination interface required for compatible P9M illuminated operators and pilot-light assemblies.
Designed for BA9S lamps up to 2 W, the P9PDNF0 supports full-voltage operation up to 380 V AC/DC under IEC ratings and up to 250 V under UL/CSA ratings. The lamp is not included, allowing a suitable BA9S light source to be selected for the required voltage and indication colour.
The P9PDNF0 uses Faston terminals for convenient electrical connection and is designed for front mounting within compatible ABB P9M assemblies. Its compact brown housing and modular construction make it suitable for demanding machinery, control-panel and heavy-industry signalling applications.
Key Advantages
- Full-voltage lamp block for ABB P9M illuminated pilot devices.
- Accepts BA9S lamps up to 2 W.
- Supports up to 380 V AC/DC under IEC ratings.
- Supports up to 250 V under UL/CSA ratings.
- Faston terminals provide convenient electrical connection.
- Front-mounted modular design simplifies integration with compatible P9M assemblies.
- Wide -30 to +70 °C operating-temperature range.
- Compact construction with a net weight of only 0.013 kg.
Key Features
- ABB P9M modular metal range.
- Full-voltage lamp block.
- BA9S lamp socket.
- Maximum lamp power of 2 W.
- 380 V AC/DC maximum IEC voltage.
- 250 V maximum UL/CSA voltage.
- Faston terminal connection.
- Front mounting.
- Brown housing.
- Lamp / bulb not included.
- Suitable for compatible illuminated P9M operators and pilot lights.
- Designed for demanding industrial control and signalling applications.
Full-Voltage Illumination for ABB P9M Pilot Devices
Lamp blocks provide the electrical interface between an industrial control circuit and the light source used inside an illuminated pushbutton, selector switch or pilot light. The ABB P9PDNF0 accepts a BA9S lamp and allows compatible P9M operators to be configured for the required indication voltage and colour.
With full-voltage operation, Faston terminals and compact front mounting, the P9PDNF0 provides a straightforward solution for industrial indication circuits. The replaceable BA9S lamp format also allows the light source to be selected separately to suit the voltage and signalling requirements of the application.
Typical Applications
- ABB P9M illuminated pushbutton assemblies.
- ABB P9M illuminated selector switches.
- Industrial pilot-light assemblies.
- Machinery status and alarm indication.
- Operator stations and control consoles.
- Manufacturing and process-control panels.
- Mining, construction and heavy-industry equipment.
